Unit Configuration
Analogue Inputs
Table 3-2: Analogue terminal list.
The DIP switch settings for connected analogue sensors must be applied according to
the table below.
Table 3-3:
Signal
Standard
accelerometer (ICP)
Voltage source
4–20 mA source
B-sensor (4–20 mA
ouput)
Eddy probe (–24 V)
Voltage powered
sensor (max 35 mA)
4–20 mA (IMx
powered)
N.C. = Not Connected
DIP switch setting 1 = ON, 0 = OFF
3 - 2
Figure 3 - 2.
IMx-S I/O Board, Analogue Inputs.
DIP switch settings for analogue sensors.
Terminal
N.C.
+ Signal/Pwr
Com.
N.C.
+ Signal
Com.
N.C.
+ Signal
– Signal
+24 V
Signal
Com.
–24 V
Signal
Com.
+24 V
Signal
Com.
+ Signal
– Signal
N.C.
DIP Settings
position: 123456
Pwr 100110
A
B
Pwr 000000
A
B
Pwr 000001
A
B
Pwr 100101
A
B
Pwr 011000
A
B
Pwr 100100
A
B
Pwr 100101
A
B
