Monitor ceases to work with a certain IMx-S unit
Possible causes:
• Loss of voltage in IMx-S unit
• Hardware fault in IMx-S unit, such as power supply or processor module
• Break in Ethernet network
Suggested solution:
• Check the voltage of IMx-S unit. In addition, check the Ethernet built-in LED
indicator behavior.
• If the problem continues, you may also refer to "Application Note Testing and
troubleshooting IMx network connections" in Application notes which is accessible
at the top right hand corner of News in Observer screen of @ptitude Observer.
Monitor completely ceases to function
Possible causes:
• Monitor PC non-functional
• Monitor software incorrectly set
• Ethernet switch non-functional
• Cable break in Ethernet network
• Firewall configuration incorrect
• Database non-functional
Suggested solution:
• Refer to "Checking monitor" in Component Check of this chapter.

Component Check

Checking sensor and sensor cabling for analogue channels
1. Determine the unit number and channel number of the channel in question
2. Measure the DC voltage between the sensor wires on the IMx-S terminal block
Table 6-1:
Sensor type
Standard accelerometer
SKF Multilog On-Line System IMx-S
User Manual
through the measurement point information in the software, or through the list
of terminal blocks.
using a digital voltmeter. See the table below for the normal voltage values
with and without a connected sensor respectively.
Normal voltage.
Normal operating bias
voltage (DC V)
8 to 12 V
Troubleshooting Guide
Component Check
Open circuit voltage (DC
V)
+24 V
6 - 3
