Technical Data

Analogue Inputs

Analogue Inputs
• Analogue differential inputs:
–
–
• Individual 24 V power supply, maximum 35 mA per channel
• Selectable standard accelerometer power supply (4 mA)
• Input range: ±25 V
• Impedance: >100 kΩ

Digital Inputs

• Digital opto-isolated inputs:
–
–
• Individual 24 V power supply, maximum 30 mA per channel:
–
–
• Trigger level range

Outputs

• Relay driver outputs:
–
–
• System relay outputs:
–
–

Analogue Measurement

• 24-bit AD conversion enabling continuous transient capture (no gain or AC/DC
switching necessary)
• True simultaneous sampling (no multiplexing):
–
–
7 - 2
IMx-S 16: 16
IMx-S 32: 32
IMx-S 16: 8
IMx-S 32: 16
IMx-S 16: 4 channels
IMx-S 32: 8 channels
IMx-S 16: 4
IMx-S 32: 8
IMx-S 16: 1
IMx-S 32: 2
IMx-S 16: all 16 channels
IMx-S 32: all 32 channels
