RDR8S and I32O16 Hardware Installation
24-10489-19 Rev. B
To remove a module from the DIN rail:
1. Pull down the clips at the bottom of the module.
2. Pull the bottom of the module out and lift it up.
Flat Surface Mounting
To mount an RDR8S or I32O16 module on a flat surface:
1. Make sure no connectors obstruct access to the clips on the bottom of
the module. If necessary, remove the connectors.
2. Fully extend the bottom clips.
3. Mount the module to the surface with mounting screws.
4. Replace the connectors, if previously removed.
Power Source
See the following table for power requirements.
Parameter
Input voltage
Input current
Power
Line Voltage Information
If the facility is located in an area where power lines are subject to frequent
lightning strikes, verify with the electric company that the building transformer
is equipped with surge protectors. These, as well as a "crowbar" type of
protection, can be installed at the main service entrance if the building
transformer is not equipped with lightning protection.
While lightning is one cause of power line transients, others can be internal or
external to the building environment. The general application of transient surge
suppression is low-cost insurance to ensure long life of the equipment being
installed.
Value
+12 to 24VDC
2A at 24V, 4A at 12V
48W
6
Mounting
