Dräger Infinity M540 Quick Reference Manual
Acute care system
Hide thumbs
Also See for Infinity M540:
- Instructions for use manual (610 pages) ,
- Quick reference manual (24 pages) ,
- Instructions for use manual (350 pages)
Related Manuals for Dräger Infinity M540
Summary of Contents for Dräger Infinity M540
- Page 1 Infinity Acute Care System This Infinity Quick Reference Quick Reference Guide Guide is not a replacement or substitute for the Instructions M540 for Use (IFU). It is for informa- tional purposes only. Software Level: VG4...
-
Page 2: Table Of Contents
INFINITY M540 QUICK REFERENCE GUIDE Content Electrode & Lead Placement Terminology Docking, Transport, Power, and Keys 8-10 Function Keys, Tabs, & Dialog Boxes 10-11 Patient Category, Admit and Discharge Audio and Visual Alarms and Silencing Alarm Priorities Views, Waveforms and Parameters... -
Page 3: Electrode & Lead Placement
INFINITY M540 QUICK REFERENCE GUIDE Electrode & Lead Placement DO’S & DO NOT’S Do place the electrode on a clean and dry area of skin. Do utilize soap, water, and dry skin thor- oughly. Do remove hair if necessary for proper elec- trode placement. - Page 4 INFINITY M540 QUICK REFERENCE GUIDE Electrode Colors* AHA/US Electrode Location Yellow Black Left arm Green Left leg White Right arm Black Green Right leg (neutral) White Brown Moveable chest Gray & White V+ Gray & Brown 2 Moveable chest Standard 6 Lead Configuration Standard 5 Lead Configuration THIS GUIDE IS INTENDED FOR REFERENCE ONLY.
- Page 5 INFINITY M540 QUICK REFERENCE GUIDE Standard 3 Lead Configuration Pacemaker Configuration 5 electrodes Warning: Make sure the pacemaker detection is turned OFF for patients without pacemakers and that it is ON for patients with pacemakers. Al- ways keep pacemaker patients under close surveillance.
- Page 6 INFINITY M540 QUICK REFERENCE GUIDE 12-Lead Configuration (ten electrodes) Respiratory lead placement for infants THIS GUIDE IS INTENDED FOR REFERENCE ONLY. REFER TO INSTRUCTIONS FOR USE MANUAL.ADDITIONAL INFORMATION © 2015 Draeger Medical, Inc.
-
Page 7: Terminology
INFINITY M540 QUICK REFERENCE GUIDE Terminology INFINITY ACUTE CARE SYSTEM (IACS) Monitors located at the bedside of the patient or accompany- ing the patient on transport. They provide continuous moni- toring and data collection of multiple parameters. Includes M540, Cockpit (C700/500), and M500. -
Page 8: Docking, Transport, Power, And Keys
INFINITY M540 QUICK REFERENCE GUIDE Docking and Transport, Power & Fre- quently Used Keys M500 DOCKING STATION WITH M540 M500 secures and powers the M540 monitor. M500 stores default profile settings that can be adopted upon docking. M500 connects M540 to Infinity network that may include an... - Page 9 INFINITY M540 QUICK REFERENCE GUIDE ON/OFF FIXED KEY Turns the M540 on or off. The button LED flashes when the M540 is undocked; is solid when the M540 is docked. BATTERY LED SYMBOL This symbol lights up when the M540 is docked to indicate the battery is being charged;...
-
Page 10: Function Keys, Tabs, & Dialog Boxes
INFINITY M540 QUICK REFERENCE GUIDE The blue header bar appears along the top of the screen. It is al- ways visible and displays the following: Remaining battery charge symbol when fully charged all segments are filled in. Segments appear empty as battery de- pletes. - Page 11 INFINITY M540 QUICK REFERENCE GUIDE Function Keys 8 Configurable keys that offer access to patient and monitor setup and review screens Function ALARMS (fixed) Opens Alarm settings dialog window. Activate All Alarms Pause or adjust Alarm volume. REVIEW (fixed) Opens the Event recall dialog window.
-
Page 12: Patient Category, Admit And Discharge
INFINITY M540 QUICK REFERENCE GUIDE Patient Category, Admit and Discharge Confirm Patient Category for Adult, Pediatric, or Neonatal Mode. If Category incorrect: Press the Menu function key. Touch the Patient setup tab. Touch Patient category and Select the appropriate category (Adult, Pediatric, &... -
Page 13: Audio And Visual Alarms And Silencing
INFINITY M540 QUICK REFERENCE GUIDE Audio & Visual Alarms and Silencing TO PAUSE AUDIO ALARMS FOR 2 MINUTES Press Audio Pause key. Note: Quiet Mode is Activated – If a new alarm condition with a priority higher than the currently paused alarm occurs, a truncated alarm tone sounds. -
Page 14: Alarm Priorities
INFINITY M540 QUICK REFERENCE GUIDE Alarm Priorities HIGH-PRIORITY ALARMS - Report conditions that require immediate intervention; for ex- ample, asystole. - The alarming parameter’s box and alarm message field have red background, and audible alarms*sound when active. - Are latched, (audio / visual alarms continue until the alarm is acknowledged, even if the alarm condition has ceased to ex- ist). -
Page 15: Views, Waveforms And Parameters
INFINITY M540 QUICK REFERENCE GUIDE Views, Waveforms and Parameters ECG, NIBP, SpO2, RRi, Temp, CO2, Invasive lines Views Each M540 supports five pre-configured views, which control the content and the appearance of the main screen. You can switch to a different view by touching the View key. Touching the View key brings up the next screen to view. -
Page 16: Setting Parameter Alarm Limits
INFINITY M540 QUICK REFERENCE GUIDE Setting Parameter Alarm Limits TO CONFIGURE ALARM LIMITS FOR EACH PARAMETER Touch a parameter box to access the parameter’s dialog win- dow (i.e., HR, NIBP). The parameter’s limits tab is viewable Touch the Upper or Lower alarm limit value. -
Page 17: Parameter Specific Settings
INFINITY M540 QUICK REFERENCE GUIDE Parameter Specific Settings ARR (ARRYTHMIA) LIMITS Touch HR parameter box > touch ARR Limits tab Touch bottom most tab along right side of dialog box to scroll to the Arrhythmia limit you want to adjust (i.e. VF, Vtach, Brady, etc.) -
Page 18: Nibp
INFINITY M540 QUICK REFERENCE GUIDE TO SELECT PACER DETECTION Touch Heart rate parameter box > touch Settings tab Touch > ECG 2 tab Touch Pacer detection – On / or Off. TO ADJUST QRS DETECTION THRESHOLD Touch Heart rate parameter box > touch Settings tab. -
Page 19: Spo2
INFINITY M540 QUICK REFERENCE GUIDE TO SUSSPEND INTERVAL MODE Press the NIBP key longer than two seconds, to set the interval to Off. To resume interval times > reset desired interval frequency in the Settings tab and initiate by pressing NIBP key... - Page 20 INFINITY M540 QUICK REFERENCE GUIDE learn the RRi waveform regularly to reduce artifact and op- timize breath count. o Manual –The monitor detects breath based on the size of the waveform. After turning on Manual mode adjust wave- form size by touching the Resp waveform dialog box and ad- just up or down to optimize the breath count.
-
Page 21: 12-Lead Ecg
INFINITY M540 QUICK REFERENCE GUIDE Snap the CO2 mainstream sensor firmly onto the airway adapter and make sure the cable is directed away from the pa- tient. Note: Always position the sensor windows of the airway adapter vertically to prevent patient secretions from obscuring the adapter window. -
Page 22: Invasive Pressures
INFINITY M540 QUICK REFERENCE GUIDE 12 Lead Monitoring Requires an additional 4 lead wire set be added to an existing 6 lead set, and 12 lead option must be enabled. TO OBTAIN A DIAGNOSTIC 12-LEAD REPORT Touch ECG parameter box > touch Settings tab. - Page 23 INFINITY M540 QUICK REFERENCE GUIDE TO ZERO ALL TRANSDUCERS Touch Zero all button on Hemopod, QuadHemo, or on C700/500. o Zeroes all transducers open to air sequentially. Note: IBP Alarms are silenced for 30 seconds for all open transducers THIS GUIDE IS INTENDED FOR REFERENCE ONLY. REFER TO INSTRUCTIONS FOR USE MANUAL.ADDITIONAL INFORMATION ©...
- Page 24 INFINITY M540 QUICK REFERENCE GUIDE HEADQUARTERS Dräegerwerk AG&Co. KGaA Moslinger Allee 53-55 23558 Lübeck, Germany www.draeger.com CANADA Draeger Medical Canada Inc, 2425 Skymark Ave Unit1 Mississauga, ON L4W 4Y6 +1 905 212 6600 Toll-free +1 866 343 2273 +1 905 Manufacturer: Draeger Medical Systems, Inc.
