Q
uick
R
eference
uide
Infinity Series Monitor
Delta/Delta XL/Kappa

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Infinity Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dräger Infinity Series

Summary of Contents for Dräger Infinity Series

  • Page 1 Infinity Series Monitor Delta/Delta XL/Kappa...

  • Page 2: Table Of Contents

    INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 01 CONTENT Lead Placement 2 - 5 Getting Started, Connecting your Patient Admit Understanding Fixed Keys Alarms Types of Alarms Adjust Arrhythmia Alarms ECG Monitoring Show All Leads Change Displayed Leads Activate Pacemaker Detection Non-Invasive Blood Pressure (NBP) Monitoring Respiratory Monitoring Change Waveform Size...
  • Page 3 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 02 Electrode & Lead Placement DO’S & DO NOT’S Place the electrode on a clean and dry area of skin. Utilize soap, water and dry. Remove hair if necessary for proper electrode placement.

  • Page 4: Lead Placement

    INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 03 5 Lead Placement White - Right Arm Green - Right Leg Black - Left Arm Red - Left Leg Brown - V2 - Left of sternum 4th intercostal space Infinity Delta/Delta XL/Kappa - Quick Reference Guide Intended for quick reference only.
  • Page 5 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 04 6 Lead Placement White - Right Arm Green - Right Leg Black - Left Arm Red - Left Leg Brown - V2 - Left of sternum 4th intercostal space Grey - V5 - Left at 5th Intercostal space Anterior Axillary line Infinity Delta/Delta XL/Kappa - Quick Reference Guide Intended for quick reference only.
  • Page 6 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 05 Pacemaker Signal Interfering with Monitor ECG QRS Detection PATIENT WITH PACEMAKER Try the following lead configurations: Five Lead Paced Patients Six Lead Paced Patients Pacemaker interference is the # 1 cause of false ASY and other arrhythmia calls.

  • Page 7: Getting Started, Connecting Your Patient

    INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 06 Getting Started - Rotary Knob The rotary trim knob at the bottom right corner of the monitor turns left and right. It highlights selections and requires pressing in to confirm the selections (click). The monitor does not need to be powered off between patients.

  • Page 8: Understanding Fixed Keys

    INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 07 Understanding Fixed Keys Alarm Silence Silences the triggered bedside alarm for 60 seconds Alarm Limits Allows limits to be set on all parameters All Alarms Off Initiates 1-5 minutes suspension of all alarms and arrhythmia processing.

  • Page 9: Alarms

    INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 08 Alarms 3 DIFFERENT TYPES OF ALARMS L-T (Life Threatening): alarm flashes red and sounds two alternating tones. L-T alarm must be manually silenced by pressing the Alarm Silence Fixed Key. SER (Serious): alarm flashes yellow and sounds the same tone twice.

  • Page 10: Ecg Monitoring

    INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 09 Accessing Parameter Functions: ECG MONITORING To Display All Monitored Leads - Highlight HR parameter box, click. - Select Show All Leads, click. HINT: For best results choose waveforms that are all positive or all negative and greater than 0.25 mv tall.

  • Page 11: Non-Invasive Blood Pressure (Nbp) Monitoring

    INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 10 Accessing Parameter Functions NON-INVASIVE BLOOD PRESSURE (NBP) MONITORING - Highlight NBP, click. - Highlight Interval Time, click. - Rotate dial to the desired time interval, click. - Press NBP Start/Stop key to begin interval setting. - To suspend interval measurements, press the NBP Start/Stop key quickly two times.

  • Page 12: Temperature Monitoring

    INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 11 TEMPERATURE MONITORING - Highlight TEMP parameter box, click. - Highlight and enter desired changes, click. Fast Access Data Key TRENDS - Press Fast Access Data key. - Highlight Trend Graph or Trend Table, click. - Highlight time interval, click.

  • Page 13: Alarm Limits Fixed Key

    INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 12 ALARM LIMITS FIXED KEY - Press Alarm Limits fixed key. - Highlight the limit to be changed, click. - Rotate dial to desired value, click. - Verify alarm status as ON/OFF as desired. NOTE: Auto Set may be used to set close to the patient specific limits.

  • Page 14: Menu Functions

    INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 13 Menu Functions PATIENT CATEGORY - Press Menu key. - Highlight Patient Setup, click. - Highlight Patient Category, click. - Select desired category, click. - Patient category Adult, Pediatric, Neonatal displayed on screen. Patient Category is displayed on screen.

  • Page 15: Transferring Patient

    INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 14 Transfer of Data TRANSFER FROM DRÄGER MONITOR TO DRÄGER MONITOR Step 1 - Press Menu key. Step 2 - Place Dräger Monitor in Standby. Step 3 - Go to destination monitor and press the Menu. Step 4 - Click on Admit/Discharge.
  • Page 16 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 15 TRANSFER FROM DRÄGER MONITOR TO M300 - Place Dräger Monitor in Standby. - Admit an M300 to the Central Station. - Click ADT. - Click Transfer. - Select Care Unit and then Monitor/Bed. - Click Continue.

  • Page 17: Troubleshooting

    INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 16 Infinity Monitor Troubleshooting Guide Arrhythmia Problems Possible Cause Action Heart rate is R wave amplitude is Select the ECG lead undercounted <than 0.5mV and/or sensitivity that provides a QRS amplitude of >0.5mV in height Heart rate is being Large P or T wave is...
  • Page 18 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 17 Arrhythmia Problems Possible Cause Action Difficulty in monitoring Pacing detection is Turn pacer detection a paced rhythm turned OFF. Pacer ON and reposition RA spike is too small and electrode lower and LL monitor is unable to electrode higher on detect.
  • Page 19 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 18 Arrhythmia Problems Possible Cause Action Fuzzy or irregular Poor lead placement. Reapply electrodes. baseline Ensure that placement Tense, uncomfortable is on flat non-muscular patient. areas. Make sure patient is comfortable. Tremors or diaphoresis. Assess and treat patient accordingly.
  • Page 20 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 19 Arrhythmia Problems Possible Cause Action Monitor did not alarm Alarm not on, criteria Access alarm limits, for arrhythmia incorrect or HR source turn on alarm with de- incorrect. ALL Alarms sired limits check HR off chosen for default source.
  • Page 21 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 20 NIBP Problems Possible Cause Action NIBP did not occur as Interval change not Initiate b/p or double desired saved. click start/stop nbp with new interval Monitor has message Leak between hose Disconnect and of NIBP open line and cuff.
  • Page 22 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 21 NIBP Problems Possible Cause Action NBP No Pulsation Weak signal. Monitor Check the patient and is unable to detect a treat if necessary. sufficient number of Check the hose and pulsations of adequate cuff.
  • Page 23 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 22 IBP Problems Possible Cause Action Pressure waveform not Loose connection Ensure that transducer showing on monitor Main screen parameter is properly connected. priority incorrect. Go to menu-main screen and highlight and shift parameter to desired location using trim knob.
  • Page 24 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 23 CO Problems Possible Cause Action CO value is different CO SETTINGS are Check CO SETTINGS form expected incorrect. CO injection and input correct takes too long. information. Inject over 10-20 Seconds. IBP S <#>...
  • Page 25 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 24 CO Problems Possible Cause Action Static Pressure Static pressure detec- Check patient and ted on the pulsatile treat if necessary. signal, owing to: A Open the system to physiological condition, the patient by turning e.g., asystole.
  • Page 26 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 25 CO Problems Possible Cause Action Calibrating Mercury calibration in Complete calibration progress. before you begin monitoring the patient. Cal. Failed – Mercury calibration Make sure transducer Not Static failed b/c input pres- is closed to patient.
  • Page 27 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 26 CO Problems Possible Cause Action Hemo Pod The hemo pod is not Check cables and Disconnected connected to monitor. connection. Replace cable if necessary. RESP Problems Possible Cause Action Respiration value Incorrect lead place- Check lead placement.
  • Page 28 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 27 RESP Problems Possible Cause Action RESP Coincidence Patient’s heart rate Observe the patient and respiration rate fall carefully. Treat if nec- within 20% of each essary. Check and or other. change the electrode placement if you receive a coincidence message until you...
  • Page 29 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 28 RESP Problems Possible Cause Action RESP Artifact Persistent artifact Check patient cable detected. and lead wires care- fully. Check electrode placement. Change their positions if necessary. No SpO reading Faulty cable/probe Check connection, connection.
  • Page 30 INFINITY DELTA/DELTA XL/KAPPA - QUICK REFERENCE GUIDE | 29 Problems Possible Cause Action Unrecognized The monitor does not Check for defective or Sensor recognize the sensor unapproved sensors. connected as valid. Replace the sensor. Contact BioMed or Dräger Medical Technical Support. Artifact A persistent artifact is Ensure the SpO...
  • Page 31 HEADQUARTERS Drägerwerk AG & Co. KGaA Moislinger Allee 53–55 23558 Lübeck, Germany www.draeger.com Manufacturer: Dräger Medical GmbH 23542 Lübeck, Germany The quality management system at Dräger Medical GmbH is certified according to ISO 13485, ISO 9001 and Annex II.3 of Directive 93/42/EEC (Medical devices).
