turck LTX Series Operating Instructions Manual
Linear position sensors with ssi interface
Hide thumbs
Also See for LTX Series:
- Operating instructions manual (22 pages) ,
- Operating instructions manual (24 pages)
Subscribe to Our Youtube Channel
Related Manuals for turck LTX Series
Summary of Contents for turck LTX Series
- Page 1 Your Global Automation Partner Linear Position Sensors with SSI Interface Operating instructions...
- Page 2 Contents Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 3: Table Of Contents
Contents About These Instructions Target groups Explanation of symbols Other documents Feedback about these instructions Information About the Product Product identification Scope of delivery Legal requirements Manufacturer and service For your Safety Intended use General safety information Product Description Device overview 4.1.1 Display elements Properties and features... - Page 4 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 5: About These Instructions
We make every effort to ensure that these instructions are as informative and as clear as pos- sible. If you have any suggestions for improving the design or if any information is missing from the instructions, please send your suggestions to techdoc@turck.com. 2019/02... -
Page 6: Information About The Product
Designs with manufacturer-compatible connectors as well as models with customer- specific blind zones are available on request. ■ LTX…M-F10-SSI2-GAF1-X3-H1161 devices are the preferred type. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 7: Scope Of Delivery
2014/30/EU (electromagnetic compatibility) Manufacturer and service Turck provides you with support and assistance for your projects — from the initial analysis to commissioning your application. The Turck product database contains software tools for pro- gramming, configuration and commissioning, as well as data sheets and CAD files in numerous export formats. -
Page 8: General Safety Information
The device complies exclusively with the EMC requirements for industrial applications and is not suitable for use in residential areas. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 9: Product Description
The devices can be connected using an M12 plug connector. All devices feature a rod design with IP68 protection. The devices operate without contact, which requires the use of a position- ing element approved by Turck (see Accessories). The devices operate on an absolute basis; power outages do not necessitate renewed zero off- set adjustment or recalibration. -
Page 10: Properties And Features
SSI inter- face. All position values are determined as absolute values; reference runs after a voltage drop are unnecessary. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 11: Automatic Signal Control
NOTE Turck recommends operating the device in asynchronous update mode, if no highly dynamic control requirement is involved. SSI Clock... -
Page 12: Measuring Functions
Preferred types LTX…M-F10-SSI2-GAF1-X3-H1161 are available with the following measuring lengths as standard: Measuring range configured 100…500 mm in 25 mm increments 500…2000 mm in 50 mm increments 2000…7600 mm in 500 mm increments Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 13: Technical Accessories
Technical accessories The following accessories are not supplied with the device: Dimension drawing Type Ident no. Description Positioning element STM-AL-R10 6900409 Standard 4-hole positioning element, alu- minum, suitable for mounting in hydraulic ø 32,8 ø 4,7 cylinders ø 23,8 ø 13,5 16,8 CM-R10 6900416... - Page 14 M12 x 1 ø 15 RKC6T-6/S618 U99-11853 6 m connection cable, M12 female connector, 6-pin, PVC, shielded M12 x 1 ø 15 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 15: Mounting
Mounting The device can be mounted in a hydraulic cylinder or externally with a mounting bracket. CAUTION Incorrect mounting Risk of damage to the sensor Secure the device in place using only the hexagon nut on the sensor head (max. ➤... -
Page 16: Mounting The Device In A Hydraulic Cylinder
Spacer for positioning element 13.5 mm bore hole in the cylinder piston rod Fig. 8: Mounting the device in a hydraulic cylinder Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 17: Fastening The Device Externally With A Mounting Bracket
Fastening the device externally with a mounting bracket CAUTION Magnetization of metal in close proximity with the measuring probe Inaccurate measurements Mount the sensor measuring probe at least 7 mm away from ferromagnetic material. ➤ ➤ NOTE Non-ferrous materials, such as brass, copper, aluminum, demagnetized stainless steel or plastic do not impair the function of the sensor. -
Page 18: Fitting Additional Mounting Elements (For External Mounting)
Mounting element for measuring probe 50.8 15.7 25.4 31.8 ø 7.1 (2x) 50.8 Fig. 10: Mounting the positioning element (dimensions in mm) Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 19: Connection
Connection CAUTION Couplings on the sensor cable Sensor fault Do not route sensor cables close to high-voltage power supplies. ➤ ➤ NOTE Keep the length of the connection cables as short as possible. ➤ ➤ Use shielded connection cables. ➤ ➤... -
Page 20: Commissioning
1 s to 0.12 s), proceed as follows: Increase the update time via the module settings of the SSI master. ➤ ➤ Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 21: Troubleshooting
Troubleshooting If the device does not function as expected, check the LED feedback (see section "LED display"). Check whether there is any ambient interference. If there is no ambient interference, check the connections of the device for faults. If no faults are identified, it indicates that the device is faulty. In this case, decommission the device and replace it with a new device of the same type. -
Page 22: Repair
Disposal The devices must be disposed of correctly and must not be included in normal household garbage. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 23: Technical Data
Technical Data Technical data LTX-R10…/LTX-F10… LTX-ER10…/LTX-EF10… Measuring range specifications Blind zone (connector end) 50.8 mm Blind zone (end) 63.5 mm Resolution Selectable, see type code Linearity ≤ 0.01% full scale Operating temperature, rod -40 °C … +105 °C Operating temperature, electronics -40 °C … +85 °C Temperature drift ≤... - Page 24 Over 30 subsidiaries and over 60 representations worldwide! D101914 | 2019/02 *D101914* www.turck.com...
