- Page 1 Your Global Automation Partner EZ-track® LTX R10 Series SSI Output Manual...
-
Page 2: Table Of Contents
Carefully remove the contents of the shipping carton and check each item on the packing slip before destroying the packing materials. Any damage must be reported to the shipping company. If you do not receive all of the parts, contact Turck at 800-544-7769. -
Page 3: Chapter 1: Ltx R10 Ssi Overview
For a translation of the model number, see Section 3.5 Part Number Key. B1406 3 www.turck.com • Phone: 763-553-7300 • Application Support: 1-800-544-7769 • Fax: 763-553-0708 • Turck Minneapolis, MN 55441... - Page 4 (frequency) of the controller. CLOCK DATA SAMPLING AT SAMPLING AT FALLING EDGE RISING EDGE SAMPLING BETWEEN EDGES 4 B1406 www.turck.com • Phone: 763-553-7300 • Application Support: 1-800-544-7769 • Fax: 763-553-0708 • Turck Minneapolis, MN 55441...
- Page 5 Figure 1-1 LTX R10 SSI Dimension Drawing B1406 5 www.turck.com • Phone: 763-553-7300 • Application Support: 1-800-544-7769 • Fax: 763-553-0708 • Turck Minneapolis, MN 55441...
-
Page 6: Chapter 2: Installing
The diameter of this magnet assembly should not be more than 0.2" away from the rod. Split magnet assemblies outside of this range will cause signal loss. 6 B1406 www.turck.com • Phone: 763-553-7300 • Application Support: 1-800-544-7769 • Fax: 763-553-0708 • Turck Minneapolis, MN 55441... -
Page 7: Installing In A Hydraulic Cylinder
0.405”. Use standard practices for machining and mounting these components. Consult the cylinder manufacturer for details on applicable SAE or military specifications. B1406 7 www.turck.com • Phone: 763-553-7300 • Application Support: 1-800-544-7769 • Fax: 763-553-0708 • Turck Minneapolis, MN 55441... - Page 8 EZ-track and will void your warranty. To tighten the EZ-track within the bracket, use the 1.75" hex mount- ing base on the head assembly. 8 B1406 www.turck.com • Phone: 763-553-7300 • Application Support: 1-800-544-7769 • Fax: 763-553-0708 • Turck Minneapolis, MN 55441...
- Page 9 2. Measure perpendicularity to A at this diameter. 3. This dimension applies when tap drill cannot pass through entire boss. 4. This dimension does not conform to SAE J1926-1. B1406 9 www.turck.com • Phone: 763-553-7300 • Application Support: 1-800-544-7769 • Fax: 763-553-0708 • Turck Minneapolis, MN 55441...
-
Page 10: Chapter 3: Wiring
+30 VDC. The power supply must be rated at 150mA minimum. The power supply should provide less than 1% ripple and 10% regulations. (The power supply should be dedicated to the EZ-track to prevent noise from external loads from affecting the position readings.) 10 B1406 www.turck.com • Phone: 763-553-7300 • Application Support: 1-800-544-7769 • Fax: 763-553-0708 • Turck Minneapolis, MN 55441... - Page 11 Chapter 3: Wiring Connections (Continued) Cable lengths Turck recommends that the maximum cable length be 10 meters. Cables greater than 10 Meters are available; however, proper care must be taken during installation. Any extension to the existing cabling should be mounted in a junction box free of any other cabling, the cable should be a twisted shielded pair with a braded shield.
- Page 12 Note: If the controller or interface module does not specify Synchronous mode, we recommend using the LDT in the Asynchronous mode. 12 B1406 www.turck.com • Phone: 763-553-7300 • Application Support: 1-800-544-7769 • Fax: 763-553-0708 • Turck Minneapolis, MN 55441...
-
Page 13: Features
Alarm Bit The LTX R10 can be configured to output a fault bit should there be a problem with the EZ-track. Consult Factory. B1406 13 www.turck.com • Phone: 763-553-7300 • Application Support: 1-800-544-7769 • Fax: 763-553-0708 • Turck Minneapolis, MN 55441... -
Page 14: Troubleshooting
1.3 watts). If the cabling checks out in step 6 and your voltage is below 7 VDC, check your power supply cur- rent rating. If voltage is between 7 to 30 VDC and the EZ-track is still inoperative, contact factory. 14 B1406 www.turck.com • Phone: 763-553-7300 • Application Support: 1-800-544-7769 • Fax: 763-553-0708 • Turck Minneapolis, MN 55441... -
Page 15: Specifications
316 stainless steel, Rod End / Mounting Hex: 0.405" (10.29 mm) outer diameter LED: Tri-color diagnostic Protection Rating: IP68 Agency Approval: B1406 15 www.turck.com • Phone: 763-553-7300 • Application Support: 1-800-544-7769 • Fax: 763-553-0708 • Turck Minneapolis, MN 55441... -
Page 16: Part Number Key
4 meter Cable, Right Angle Cordset ....WKC 6T-4/S618 Split Magnet Spacer ..............SPS-R10 Cylinder Magnet ..............CM-R10 Mounting Bracket Kit .............MB-R10 Rod Support Bracket ...............RB-R10 Magnet Mount Bracket .............MMB-R10 16 B1406 www.turck.com • Phone: 763-553-7300 • Application Support: 1-800-544-7769 • Fax: 763-553-0708 • Turck Minneapolis, MN 55441... - Page 17 Notes: B1406 17 www.turck.com • Phone: 763-553-7300 • Application Support: 1-800-544-7769 • Fax: 763-553-0708 • Turck Minneapolis, MN 55441...
- Page 18 Notes: 18 B1406 www.turck.com • Phone: 763-553-7300 • Application Support: 1-800-544-7769 • Fax: 763-553-0708 • Turck Minneapolis, MN 55441...
- Page 19 Notes: B1406 19 www.turck.com • Phone: 763-553-7300 • Application Support: 1-800-544-7769 • Fax: 763-553-0708 • Turck Minneapolis, MN 55441...
- Page 20 28 subsidiaries and over 60 representations worldwide! Printed in USA ©2015 by Turck Inc. All rights reserved. No part of the www.turck.com B1406 A 10/15 publication may be reproduced without written permission.
