i.MX 8M Mini SODIMM Development Platform Hardware User Guide
2.6

High Speed Interfaces

2.6.1 Mini PCIe Port

i.MX 8M Mini SODIMM Carrier Board supports Mini PCIe connector to support Mini-PCIe device. Optional 0E resistor R166
for PCIE_RXM and R170 for PCIE_RXP has been populated at the connector receiver signal side for PCIe device coupling
option. Mini PCIe connector (J20) is physically located at bottom of the board as shown below
Note: Either Mini PCIe connector or 2

Table 6: Mini PCIe Slot Pin Out

Pin
Pin Name
No
1
Wake#
2
VCC_PCIe3V3
3
COEX1
4 GND
5 COEX2
6 VCC_1V5_3G
7 CLKREQ#
8 UIM_PWR
9 GND
10 UIM_DATA
11 PCIE_REFCLK_DM(CLK1_N) PCIE_REFCLK_DM
iWave Systems Technologies Pvt. Ltd.

Figure 10: Mini PCIe Slot

nd
Ethernet Magjack can be supported at a time.
Signal Name
PCIe_WAKE_B(GPIO1_10)
VCC_PCIe3V3
NC
GND
NC
VCC_1V5_3G
NC
NC
GND
NC
Signal Type /
Termination
I, 3.3V CMOS
PCIe interface Wake Up Signal.
10K UP
O, 3.3V Power 3.3V Power Supply.
- NC.
Power Ground.
- NC.
O, 1.5V Power Supply for 3G
- NC.
- NC.
Power Ground.
- NC.
O, DIFF PCIe reference clock negative.
Description
REL1.0
Page 33 of 55
