8
Hardware layout and configuration
The B-G474E-DPOW1 Discovery kit is designed around the STM32G474RET6 microcontroller, in 64-pin LQFP
package. The hardware block diagram (Refer to
and the peripherals (RGB power LED and buck LED, digital power buck-boost, LTC3114 5 V converter,
embedded ST-LINK/V3E, USB Type-C
connector headers).
UM2577 - Rev 2
Figure
®
2.0 FS, 4 user LEDs and a joystick as user interface, 2 x 32 pin extension
Figure 4
and
Figure 5
help to locate these features on the
Hardware layout and configuration
3) illustrates the connection between the microcontroller
B-G474E-DPOW1
UM2577
board.
page 9/54
