VOUT resistor
The buck-boost converter function is composed of symmetrical half-bridge topology and works in either Buck,
Boost, or Buck-boost mode. It leverages advanced HRTimers, FMAC, and digital slope compensation
management. It integrates a current regulation in Buck mode and is able to measure average and instantaneous
currents at buck-boost converter input (thanks to ADC and internal comparator). Input and output voltage
regulations are managed thanks to the ADC channels usage. A current sensing function allows implementing
current protection at digital buck-boost converter input VIN.
By default, double switch function isolates USB Type-C
switch is controlled by the activation of BUCKBOOST_USBPD_EN (PC3). Activation of this double switch
connects the USBPD_VBUS to bring power to the buck-boost converter input VIN if JP1 is set correctly.
By default, the VIN header JP1 selects power source from USBPD_VBUS of USB Type-C
a closing jumper to connect USBPD and VIN [1-2]. The user may also want to use external VIN, and in that case,
must connect an external power supply on VIN and GND pins of the JP1 header, and the JP1 jumper must be
removed.
UM2577 - Rev 2
Figure 17.
Embedded
loads
JP1
VIN selection
Figure 18.
Digital power buck-boost converter
®
V from the buck-boost converter input. The double
BUS
JP1 VIN default configuration
UM2577
Digital power buck-boost converter
JP2 / JP3
headers
CN7 (top)
VOUT / GND
®
CN3 connector, with
page 28/54
