CN11
Corner jumper
CN10
TAG connector
CN8
32-pin extension
connector
CN7
VOUT extension
connector
CN11
Corner jumper
UM2577 - Rev 2
Figure 5.
B-G474E-DPOW1 bottom layout view
UM2577
Product layout (top and bottom)
CN12
Corner jumper
CN9
32-pin extension
connector
CN6
Corner jumper
page 12/54
