Board overview

The STEVAL-ISB68RX evaluation board default configuration is optimized for performance.
The board features:
• STWLC68JRH wireless power receiver chip with up to 5 W output power capability (Qi specification 1.2.4,
BPP)
• Constant 5 V output voltage (default setting)
• Total (TX input to RX output) system efficiency up to 80%
• Foreign Object Detection (FOD) supported
• 400 kHz I2C interface for communication with host system (optional)
• Built-in USB-to-I
• Configurable GPIOs (e.g. status monitoring or auxiliary control signals)
• Solder pads matrix for customization of evaluation board
• Complete kit (Board with embedded receiving coil, Graphical User Interface control software)
• RoHS compliant
UM2681 - Rev 1
2
C converter for interfacing to STWLC68JRH chip
