Recessed TV Wall Mount
Instruction Manual
SKU: MOUNT-REC01
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-rec01
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo MOUNT-REC01
Summary of Contents for Vivo MOUNT-REC01
- Page 1 Recessed TV Wall Mount Instruction Manual SKU: MOUNT-REC01 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-rec01 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
CAUTION! DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting for brick and concrete walls. If unsure, please contact us at vivo-us. com, email at help@vivo-us.com, or call us at 309-278-5303. -
Page 3: Tools Needed
TOOLS NEEDED Phillips Tape Measure Stud Finder Screwdriver Pencil Drill 3mm Drill 10mm Drill Drywall Saw 13mm Socket ASSEMBLY STEPS STEP 1 (Option A) Wood Stud Installation Find stud locations using a stud finder and mark the edge of each stud. Hold the mount up between two studs at the desired height with the back side touching the wall and trace the perimeter using a pencil. - Page 4 STEP 1 (Option B) Concrete/Brick Installation Find the edges the concrete/brick pillar. If covered in drywall, hold Mount (A) with Bubble Level (T-B) up to the desired mounting location with the back side touching the wall and trace the perimeter using a pencil.
- Page 5 STEP 2 (Option B) Concrete/Brick Installation Slide the tabs on the left side of Arm (B) into the slots on Mount (A). Loosen the screws on Arm (B) using 4mm Allen Wrench (T-A). Extend the arms until it reaches the right pillar. Make sure the arm is level then tighten screws.
- Page 6 STEP 4 Secure Bracket Rails (C) to Arm (B) using M6x12mm Screws (S-B) and 4mm Allen Wrench (T-A). Insert M4x6mm Screws (S-A) into the back of Bracket Rails (C) using a Phillips screwdriver. STEP 5 (Option A) Flat Back Monitor Attach VESA Brackets (D) to the back of the TV using combination of Screws (M-A through M-H) and M6 Washers (M-I).
- Page 7 STEP 6 Hang the TV with VESA Brackets (D) onto Bracket Rails (C). STEP 7 Flip the latch on the underside of VESA Brackets (D) and tighten the security screws using a Phillips screwdriver to secure them in place. Install Cable Managment Clips (E) onto Arm (B) and route cables through the clips and Cable Grommets (F).
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
