PANEL METER FOR INW PT12 SENSOR

Introduction

What is an INW Panel Meter for an INW PT12 Smart Sensor?

This is a Modbus meter that is specially configured to read an INW PT12 Pressure/
®
Temperature Smart Sensor.
By default, the meter displays pressure in PSI. The meter can also be set to display
pressure in feet of water or meters of water or to display temperature in degrees Celsius.
The meter is available in either an 85 - 265 VAC version for wired-in power or in a
12 VDC version for remote or portable usage.
The meter comes installed in a weatherproof Nema 4X enclosure with the PT12 Smart
Sensor connected through a wire seal.
An INW PT12 Smart Sensor is a submersible pressure/temperature sensor which
can communicate via Modbus, as well as SDI-12. When used with this meter, the
sensor communicates via Modbus.

Initial Inspection and Handling

Upon receipt of your meter, inspect the shipping package for damage. If any damage
is apparent, note the signs of damage on the appropriate shipping form. After opening
the carton, look for concealed damage. If concealed damage is found, immediately file
a claim with the carrier.

Do's and Don'ts

Do handle the device with care.
Don't install the device so that the box or connector is submerged.
Don't bang or drop the device on hard objects.
