1

Getting started

1.1

Overview

The
•
•
•
•
•
•
•
•
•
•
•
•
The SPI interface and the embedded power good detection allow a deeper diagnostics, daisy chaining and less
MCU GPIO resources on the PLC logic stage.
Note: The X-NUCLEO-OUT02A1 offers a digital output solution: each output stage is managed at microcontroller level.
As the board has no input stage, no sensors can be connected to it.
1.2

Hardware requirements

To use
via the Arduino™ UNO R3 connector pins on the STM32 Nucleo development board.
UM2507 - Rev 1
Arrow.com. Arrow.com.
Downloaded from Downloaded from
X-NUCLEO-OUT02A1 expansion board features:
Based on the ISO8200AQ whose main characteristics are:
– Embedded 4kV galvanic isolation
– Radio frequency communication between the logic and process sides for maximum noise immunity
– Very low power dissipation (R
– Fast decay for inductive loads
– 20 MHz SPI I/F on logic side
– V power good diagnostics
CC
– Overload and overheating protections with thermal shutdown and diagnostics
– QFN-32L (9x11x1 mm) package
10.5 to 33 V operating voltage range
Green LED (x8) for output on/off status
Red LED for process supply power good fault
Red LED for overload and overheating
Supply reverse polarity protection
EMC compliance according to IEC61000-4-2, IEC61000-4-3, IEC61000-4-5
Compatible with STM32 Nucleo
Equipped with Arduino™ UNO R3 connectors
CE certified
RoHS and China RoHS compliant
WEEE compliant
STM32 Nucleo development boards with the
= 220 mΩ)
ON(MAX)
boards
X-NUCLEO-OUT02A1
UM2507
Getting started
expansion board, match the boards
page 2/14
