For EMC:
•
•
•
To supply the load, connect the supply voltage to the J1 2-way screw connector. The load is connected to the 8-
way output.
UM2507 - Rev 1
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Figure 4. X-NUCLEO-OUT02A1 expansion board: power section components
a Transil™ diode SMC30J30CA
for common mode surge testing, two single-layer capacitors (C1 and C3, not mounted) must be soldered;
22 nF capacitors are included on the output lines for burst disturbance filtering.
is placed on V track to protect the
CC
UM2507
Power section
ISO8200AQ against surge discharge;
page 5/14
