ESVK/KRV86 - ESVK/KRV88 Series "2 wire Bus" videokit
System components and available versions
ESVKX/KRV86 - ESVKX/KRV88
OUTDOOR
STATION
Camera unit
Art. 4384X
pag. 10
Fig. 2 - ESVKX/KRV86 - ESVKX/KRV88 components (measures in mm)
ESVKX-1/6788 - flush mounting
1 Outdoor station composed of:
1 Art. 4384X-1: 1 button camera unit
1 Art. 4851:
ESVKX-1S/6788 - surface mounting
1 Outdoor station composed of:
1 Art. 4384X-1: 1 button camera unit
1 Art. 4881:
ESVKX-2/6788 - flush mounting
1 Outdoor station composed of:
1 Art. 4384X-2: 2 buttons camera unit
1 Art. 4851:
ESVKX-2S/6788 - surface mounting
1 Outdoor station composed of:
1 Art. 4384X-2: 2 buttons camera unit
1 Art. 4881:
ESVK/KRV86 - ESVK/KRV88 Series - Installation handbook
135,0
120,0
Flush mounting box
Surface mounting box
Flush mounting box
Surface mounting box
Colour videokit with embended proximity key reader.
45,0 22,7 50
15,7
43,8
Flush Surface
Mounting Mounting
1 Colour videophone
Art. KRV86 or
or
Art. KRV88
1 Colour videophone
Art. KRV86 or
or
Art. KRV88
2 Colour videophones
Art. KRV86 or
or
Art. KRV88
2 Colour videophones
Art. KRV86 or
or
Art. KRV88
- 4 -
INDOOR STATION
Videophone
Art. KRV86 or
Art. KRV88
pag. 23
ACCESSORIES
Power supply
Art. 2321
pag. 1
Card format fob
Art. 955/C
Tag format fob
Art. 955/T
1 Power supply
Art. 2321
1 Card format fob
Art. 955/C
2 Tag format fobs
Art. 955/T
1 Power supply
Art. 2321
1 Card format fob
Art. 955/C
2 Tag format fobs
Art. 955/T
1 Power supply
Art. 2321
1 Card format fob
Art. 955/C
4 Tag format fobs
Art. 955/T
1 Power supply
Art. 2321
1 Card format fob
Art. 955/C
4 Tag format fobs
Art. 955/T
