VIDEOKIT
ESVK/6788 SERIES
"2 Wire" bus one way, two way videokit
ESVK
Rev.0.2
ESVKX
ESVKC
66550029-EN - V6.6 - 31/08/22
Rev.0.2
Rev.0.3
Installation handbook
6788
We recommend
This equipment is installed by a
Competent Electrician, Security or
Communications Engineer.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESVK/6788 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Videx ESVK/6788 Series

Summary of Contents for Videx ESVK/6788 Series

  • Page 1 VIDEOKIT ESVK/6788 SERIES “2 Wire” bus one way, two way videokit ESVK Rev.0.2 ESVKX Rev.0.2 ESVKC Rev.0.3 6788 Installation handbook We recommend 66550029-EN - V6.6 - 31/08/22 This equipment is installed by a Competent Electrician, Security or Communications Engineer.
  • Page 2 This manual has been written and revised carefully. The instructions and the descriptions which are included in it are referring to VIDEX parts and are correct at the time of print. However, subsequent VIDEX parts and manuals, can be subject to changes without notice.

  • Page 3: System Components And Available Versions

    ESVK/6788 Series “2 wire Bus” videokit System components and available versions ESVK/6788 Colour videokit. OUTDOOR INDOOR STATION STATION 135,0 45,0 22,7 Videophone Art. 6788 pag. 22 Camera unit Art. 4384 pag. 1 ACCESSORIES Power supply Art. 2321 pag. 27 15,7 43,8 120,0 Flush...
  • Page 4 ESVK/6788 Series “2 wire Bus” videokit System components and available versions ESVKX/6788 Colour videokit with embended proximity key reader. OUTDOOR INDOOR STATION STATION Videophone 135,0 45,0 22,7 Art. 6788 pag. 22 Camera unit Art. 4384X pag. 1 ACCESSORIES Power supply Art. 2321 pag. 27...
  • Page 5 ESVK/6788 Series “2 wire Bus” videokit System components and available versions ESVKC/6788 Colour videokit plus a codelock module. OUTDOOR INDOOR STATION STATION Videophone 135,0 45,0 22,7 Art. 6788 pag. 22 Camera unit Art. 4384 pag. 1 ACCESSORIES Power supply Art. 2321 pag. 27...

  • Page 6: General Directions For Installation

    40nF and is an accumulation of all lengths and branches of the cable. For example: because of cable capaci- tance, the Videx CM2 cable used in a single system cannot exceed the 400m considering all lengths and branches of the cable.
  • Page 7 ESVK/6788 Series “2 wire Bus” videokit General directions for installation CABLES LENGTH & SIZE 7" Videophones Art.6788 Art.KRV782 Wires Section Cable Type B max (mm2) VIDEX CM2 0.50 CAT5 UTP/CW1308 0.22 Std Telephone Cable 0.28 Standard wire Art.2321 - 7 - ESVK/6788 Series - Installation handbook 66550029-EN - V6.6 - 31/08/22...
  • Page 8 ESVK/6788 Series “2 wire Bus” videokit General directions for installation CABLES LENGTH & SIZE 7" Videophones 7" Videophones Art.6788 Art.KRV782 Art.6788 Art.KRV782 Wires Section Cable Type B max (mm2) VIDEX CM2 0.50 Art318 CAT5 UTP/CW1308 0.22 Std Telephone Cable 0.28 Standard wire Art.2321...
  • Page 9 ESVK/6788 Series “2 wire Bus” videokit General directions for installation CABLES LENGTH & SIZE 7" Videophones 7" Videophones Art.6788 Art.KRV782 Art.6788 Art.KRV782 Wires Section Cable Type B max (mm2) VIDEX CM2 0.50 Art.317N CAT5 UTP/CW1308 0.22 Std Telephone Cable 0.28 Standard wire * Using the active distributor Art. 317N, the maximum ca-...

  • Page 10: Available Versions

    ESVK/6788 Series “2 wire Bus” videokit Art. 4384 Speaker unit with built-in camera Art. 4384X Speaker unit with built-in camera & proximity key reader 4384-0 4384-1 4384-2 4384X-0 4384X-1 4384X-2 STEEL HIGH BRASS MATTE GUN METAL Made in Italy 1 2 3 4 5 6 7 8...
  • Page 11 ESVK/6788 Series “2 wire Bus” videokit Art. 4384 Speaker unit with built-in camera Art. 4384X Speaker unit with built-in camera & proximity key reader PROGRAMMING The programming consists of the following settings: • Unit ID (1..15); • Door opening time (2 or 6 seconds);...
  • Page 12 ESVK/6788 Series “2 wire Bus” videokit Art. 4384 Speaker unit with built-in camera Art. 4384X Speaker unit with built-in camera & proximity key reader RS485 CONNECTION switch to RS485 position With switch 8 in ON position the module can be connected using an...

  • Page 13: Operation

    ESVK/6788 Series “2 wire Bus” videokit Art. 4384 Speaker unit with built-in camera Art. 4384X Speaker unit with built-in camera & proximity key reader HOW TO CONNECT AN ELECTRIC LOCK The “door-open” relay can operate either as “dry contact” or “capacitive discharge” mode.

  • Page 14: Using Tags

    ESVK/6788 Series “2 wire Bus” videokit Art. 4384 Speaker unit with built-in camera Art. 4384X Speaker unit with built-in camera & proximity key reader PROGRAMMING TAGS (ONLY ART. 4384X VERSIONS) MASTER TAG The external module is supplied with a master tag. The master tag is programmed in-factory, it is white to easily stand out. This tag enables user tags to be programmed or cleared.
  • Page 15 ESVK/6788 Series “2 wire Bus” videokit Art. 4384 Speaker unit with built-in camera 4384-0 Art. 4384X Speaker unit with built-in camera & proximity key reader 4384-1 4384-2 REPROGRAMMING A MASTER TAGS 4384X-0 4384X-1 4384X-2 If the master tag is lost or damaged, a new one can be programmed using the following procedure:...
  • Page 16 ESVK/6788 Series “2 wire Bus” videokit Art. 4384 Speaker unit with built-in camera Art. 4384X Speaker unit with built-in camera & proximity key reader FIELDS OF VIEW MAXIMUM ILLUMINATION DISTANCE FROM CAMERA AT NIGHT The fields of view for standard camera are 55° for vertical angle and 115° for horizontal angle while for Wide Angle camera are 80°...

  • Page 17: Main Features

    GENERAL DIRECTIONS FOR INSTALLATION In order to achieve the best results from the schematics described it is necessary to install only original VIDEX equipment, strictly keeping to the items indicated on each schematic and follow these General Directions for Installation: •...
  • Page 18 ESVK/6788 Series “2 wire Bus” videokit Art. 4901 Digital codelock module LOCK RELEASE BACK EMF PROTECTION A varistor must be fitted across the ter- VARISTOR (MOV) DIODE 1N4002 minals on AC lock release (Fig. 3) and a diode must be fitted across the ter- minals on a DC lock release (Fig.
  • Page 19 ESVK/6788 Series “2 wire Bus” videokit Art. 4901 Digital codelock module PROGRAMMING • Enter the ENGINEER’S CODE: first time type six times 1 (111111 ENTER THE Six times 1 “111111” factory preset) and press ENTER (The red LED will illuminate); "ENGINEER’S CODE"...
  • Page 20 ESVK/6788 Series “2 wire Bus” videokit 4000 Series Surface and flush mounting door station installation EXAMPLE: INSTALLING A FOUR MODULE OUTDOOR STATION fig. 1 fig. 2 fig. 3 fig. 4 fig. 5 fig. 6 fig. 7 fig. 8 fig. 9 fig.
  • Page 21 ESVK/6788 Series “2 wire Bus” videokit 4000 Series Surface and flush mounting door station installation INSTALLING A SURFACE MOUNT DOOR STATION 1. Place the surface box against the wall (165-170cm between the top of the box and the floor level as shown in Fig. 1) and mark the fixing holes for the wall plugs and the hole for the cables (fig. 2).

  • Page 22: Push Buttons

    ESVK/6788 Series “2 wire Bus” videokit Art. 6788 7" hands free colour display digital videophone R03A(-2) 27mm 200mm PT3 PT2 1 2 3 6 7 8 1 2 3 4 Fig. 2 Back Fig. 1 Front DESCRIPTION LEGEND Surface mount hands free intelligent Videophone using 7” full Connection terminals colour active matrix LCD monitor for VX2300.

  • Page 23: Number Of Rings

    ESVK/6788 Series “2 wire Bus” videokit Art. 6788 7" hands free colour display digital videophone PUSH BUTTONS Answer push button. On an incoming call, operation of this button allows the user to answer and converse with the visitor. The relevant LED will illuminate.
  • Page 24 ESVK/6788 Series “2 wire Bus” videokit Art. 6788 7" hands free colour display digital videophone MELODY SELECTION • Keep pressed the button until the two LEDs switch on. The unit emits the first melody. • Press the button and keep it pressed to listen the next melody. Repeat the operation until the required melody is found.

  • Page 25: Memory Board

    ESVK/6788 Series “2 wire Bus” videokit Art. 6788 7" colour display videophone EXTENSION NO – SW3.2..3 If the intercommunication between apartments is enabled (switch 1 of SW3 = ON) EXTENSION NO. leave these two switches in default position (both to OFF). Otherwise, if the in-...

  • Page 26: Wall Mounting Instructions

    ESVK/6788 Series “2 wire Bus” videokit 6700 Series Wall mounting instructions Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6 Fig. 7 1. In order to install the videophone, it is necessary to remove the cover, which contains all the electronics, from the base: then rotate clockwise until you listen a “CLICK!”.

  • Page 27: Power Supplies

    ESVK/6788 Series “2 wire Bus” videokit Art. 2321-2321/P Power supplies 157.5 160.3 62.5 Art.2321 Art.2321/P 96,8 Fig. 1 Art. 2321 Fig. 2 Art. 2321/P (Rev.0.1) DESCRIPTION LEGEND Power supplies specifically designed for VX2300 digital system. Mains input The Art. 2321 can be used for systems with 1 entrance up to 20 users.

  • Page 28: Technical Specification

    ESVK/6788 Series “2 wire Bus” videokit Art. 2322 Power supply converter from BUS line to 12 Vdc Art.2322 Fig. 1 Fig. 2 DESCRITPION LEGEND When this unit is connected to the BUS line it generates a Connection terminals +12Vdc – 100mA power source. This unit can be used to supply peripherals such as the Art. 4901 or Art. 4902 without the need...

  • Page 29: Push Button Configuration

    4, 6, 8 or 10 call push buttons. (only for double row versions) figuration jumpers J2 and J1 jumpers to con- Specific for use in combination with VIDEX IPURE, VX2200, Name plate holders VX2300 camera moduels/speaker units and GSM speaker untis Right side push button figure illumination LEDs with IDC connector.
  • Page 30 ESVK/6788 Series “2 wire Bus” videokit Art. 4042 .. 4045 Single row button expansion modules Art. 4042D .. 4045D Double row button expansion modules POWER SUPPLY To give power supply to the module connect one of the inbuilt IDC male connector to the IDC male connector of the camera unit module through the flat cable provided.
  • Page 31 ESVK/6788 Series “2 wire Bus” videokit Art. 4042 .. 4045 Single row button expansion modules Art. 4042D .. 4045D Double row button expansion modules ADHESIVE GASKET PLACEMENT Apply the seal as shown in Fig. 6. ANTI-TAMPERING LOCKS FIXING Fit the anti-tampering locks as shown in Fig.
  • Page 32 Foglio ESVK-1/6788, ESVK-1S/6788 One Way Videokit 10/06/2020 Titolo: Data modifica: ESVK-1/6788, ESVK-1S/6788 Videokit Monofamiliare 27/10/2020 Videx Electronics S.p.A. Notes: Autore: Marco Rongoni Via del Lavoro 1, 63846 Monte Giberto (FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 4384-67h-001.dwg...
  • Page 33 Foglio ESVK-2/6788, ESVK-2S/6788 Two Way Videokit 10/06/2020 Titolo: Data modifica: ESVK-2/6788, ESVK-2S/6788 Videokit Bifamiliare 27/10/2020 Videx Electronics S.p.A. Notes: Autore: Marco Rongoni Via del Lavoro 1, 63846 Monte Giberto (FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 4384-67h-002.dwg...
  • Page 34 Foglio ESVKC-1/6788, ESVKC-1S/6286 One Way Videokit 12/06/2020 Titolo: Data modifica: ESVKC-1/6788, ESVKC-1S/6788 Videokit Monofamiliare 27/10/2020 Videx Electronics S.p.A. Notes: Autore: Marco Rongoni Via del Lavoro 1, 63846 Monte Giberto (FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 4384-67h-003.dwg...
  • Page 35 Foglio ESVKC-2/6788, ESVKC-2S/6788 Two Way Videokit 10/06/2020 Titolo: Data modifica: ESVKC-2/6788, ESVKC-2S/6788 Videokit Bifamiliare 27/10/2020 Videx Electronics S.p.A. Notes: Autore: Marco Rongoni Via del Lavoro 1, 63846 Monte Giberto (FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 4384-67h-004.dwg...
  • Page 36 10/06/2020 Titolo: Data modifica: ESVK-1/6788, ESVK-1S/6788 Videokit Monofamiliare con citofono addizionale, relé per l'estensione della suoneria, relé per due servizi addizionali e telecamera esterna 27/10/2020 Videx Electronics S.p.A. Notes: Autore: Marco Rongoni Via del Lavoro 1, 63846 Monte Giberto (FM) Note: Cod.File:...
  • Page 37 Foglio ESVK-1/6788, ESVK-1S/6788 One Way Videokit with video memory 10/06/2020 Titolo: Data modifica: ESVK-1/6788, ESVK-1S/6788 Videokit Monofamiliare con memoria video 27/10/2020 Videx Electronics S.p.A. Notes: Autore: Marco Rongoni Via del Lavoro 1, 63846 Monte Giberto (FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 4384-67h-007.dwg...
  • Page 38 To next To next Title: Data creazione: Foglio 09/06/2020 Titolo: Data modifica: 09/06/2020 Videx Electronics S.p.A. Notes: Autore: Marco Rongoni Via del Lavoro 1, 63846 Monte Giberto (FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 404x.dwg www.videx.it - info@videx.it...
  • Page 39 DISPOSAL In accordance with the Legislative Decree no. 49 of 14 March 2014 “Implementation of the Directive 2012/19/EU on waste electrical and electronic equipment (WEEE)”. The crossed-out bin symbol on the equipment or on the packaging indicates that when the product reaches the end of its lifetime, it must be collected separately from mixed municipal waste.
  • Page 40 Singapore office: VIDEX ASIA PACIFIC PTE LTD 1 TAMPINES NORTH DRIVE 1, #06-08, T-Space Singapore 528559 Phone: (+65) 81898912 commercial@videx.it The product is CE marked demonstrating its conformity and is for distribution with- Il prodotto è marchiato CE a dimostrazione della sua conformità e può essere distri- in all member states of the EU with no restrictions.
