ESVK/KRV86 - ESVK/KRV88 Series "2 wire Bus" videokit
Art. 4901
Digital codelock module
CONNECTION TERMINALS SIGNALS
SW2 Relay 2 command signal (active low)
SW1 Relay 1 command signal (active low)
NC3 Relay 3 normally closed contact
NO3 Relay 3 normally open contact
C3
Relay 3 common contact
NC2 Relay 2 normally closed contact
NO2 Relay 2 normally open contact
C2 Relay 2 common contact
NC1 Relay 1 normally closed contact
NO1 Relay 1 normally open contact
C1
Relay 1 common contact
–
12/24Vac/dc power input
+
ESVK/KRV86 - ESVK/KRV88 Series - Installation handbook
CLEANING OF THE PLATE
Use a clean and soft cloth. Use moderate warm water or non-ag-
gressive cleansers.
Do not use:
• abrasive liquids;
• chlorine-based liquids;
• metal cleaning products.
Max
TECHNICAL SPECIFICATION
24Vac/dc
Power Supply:
3A
Power Consumption:
Working Temperature:
- 20 -
12/24 Vac/dc – 2VA
Stand-by: 20mA
Operating: 70mA
-20 +60° C
66550045-EN - V6.2 - 31/10/20
