Videx ESVK/6788 Series Installation Handbook

Videx ESVK/6788 Series Installation Handbook

“2 wire” bus one way, two way videokit
Hide thumbs Also See for ESVK/6788 Series:

Advertisement

Quick Links

Download this manual
VIDEOKIT
ESVK/6788 SERIES
"2 Wire" bus one way, two way videokit
ESVK
ESVKX
ESVKC
66550029-EN - V4.0 - 15/02/19
Installation handbook
6788
We recommend
This equipment is installed by a
Competent Electrician, Security or
Communications Engineer.
Rev.0.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ESVK/6788 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Videx ESVK/6788 Series

Summary of Contents for Videx ESVK/6788 Series

  • Page 1 VIDEOKIT Rev.0.1 ESVK/6788 SERIES “2 Wire” bus one way, two way videokit ESVK ESVKX ESVKC 6788 Installation handbook We recommend 66550029-EN - V4.0 - 15/02/19 This equipment is installed by a Competent Electrician, Security or Communications Engineer.

  • Page 2: Table Of Contents

    This manual has been written and revised carefully. The instructions and the descriptions which are included in it are referring to VIDEX parts and are correct at the time of print. However, subsequent VIDEX parts and manuals, can be subject to changes without notice.

  • Page 3: System Components And Available Versions

    ESVK/6788 Series “2 wire Bus” videokit System components and available versions ESVK/6788 Colour videokit. OUTDOOR INDOOR STATION STATION 135,0 45,0 22,7 Videophone Art. 6788 pag. 20 Camera unit Art. 4333 pag. 10 ACCESSORIES Power supply Art. 2321 pag. 25 15,7 43,8 120,0 Flush...
  • Page 4 ESVK/6788 Series “2 wire Bus” videokit System components and available versions ESVKX/6788 Colour videokit with embended proximity key reader. OUTDOOR INDOOR STATION STATION Videophone 135,0 45,0 22,7 Art. 6788 pag. 20 Camera unit Art. 4333X pag. 10 ACCESSORIES Power supply Art. 2321 pag. 25...
  • Page 5 ESVK/6788 Series “2 wire Bus” videokit System components and available versions ESVKC/6788 Colour videokit plus a codelock module. OUTDOOR INDOOR STATION STATION Videophone 135,0 45,0 24,0 51,0 Art. 6788 pag. 20 Camera unit Art. 4333 pag. 10 ACCESSORIES Power supply Art. 2321 pag. 25...

  • Page 6: General Directions For Installation

    40nF and is an accumulation of all lengths and branches of the cable. For example: because of cable capaci- tance, the Videx CM2 cable used in a single system cannot exceed the 400m considering all lengths and branches of the cable.
  • Page 7 ESVK/6788 Series “2 wire Bus” videokit General directions for installation CABLES LENGTH & SIZE 7" Videophones Art.6788 Art.KRV782 Wires Section Cable Type B max (mm2) VIDEX CM2 0.50 CAT5 UTP/CW1308 0.22 Std Telephone Cable 0.28 Standard wire Art.2321 - 7 - ESVK/6788 Series - Installation handbook 66550029-EN - V4.0 - 15/02/19...
  • Page 8 ESVK/6788 Series “2 wire Bus” videokit General directions for installation CABLES LENGTH & SIZE 7" Videophones 7" Videophones Art.6788 Art.KRV782 Art.6788 Art.KRV782 Wires Section Cable Type B max (mm2) VIDEX CM2 0.50 Art318 CAT5 UTP/CW1308 0.22 Std Telephone Cable 0.28 Standard wire Art.2321...
  • Page 9 ESVK/6788 Series “2 wire Bus” videokit General directions for installation CABLES LENGTH & SIZE 7" Videophones 7" Videophones Art.6788 Art.KRV782 Art.6788 Art.KRV782 Wires Section Cable Type B max (mm2) VIDEX CM2 0.50 Art.317N CAT5 UTP/CW1308 0.22 Std Telephone Cable 0.28 Standard wire * Using the active distributor Art. 317N, the maximum ca-...
  • Page 10 ESVK/6788 Series “2 wire Bus” videokit Art. 4333/4333X Rev.0.1 Speaker unit module with built-in functional to digital interface Balance 4333-0 4333-1 4333-2 4333X-0 4333X-1 4333X-2 Made in Italy STEEL HIGH BRASS MATTE 1 2 3 4 5 6 7 8 Fig. 1 Fig.
  • Page 11 ESVK/6788 Series “2 wire Bus” videokit Art. 4333/4333X Speaker unit module with built-in functional to digital interface FRONT LEDS SIGNALLING DESCRIPTION When illuminated, indicates that it is not possible to make a call because a call or a conversation is in progress (from the outdoor station from which you are calling or from another outdoor station on systems with multiple entranc- es).

  • Page 12: Art. 4333/4333X Speaker Unit Module With Built-In Functional To Digital Interface

    ESVK/6788 Series “2 wire Bus” videokit Art. 4333/4333X Speaker unit module with built-in functional to digital interface PROGRAMMING TAGS (FOR ART. 4333X) MASTER TAG The external module is supplied with a master tag. The master tag is programmed in-factory, it is white to easily stand out. This tag enables user tags to be programmed or cleared.
  • Page 13 ESVK/6788 Series “2 wire Bus” videokit Art. 4333/4333X Speaker unit module with built-in functional to digital interface REPROGRAMMING A MASTER TAGS If the master tag is lost or damaged, a new one can be programmed using the following procedure: 1. Switch off the power.
  • Page 14 ESVK/6788 Series “2 wire Bus” videokit Art. 4333/4333X Speaker unit module with built-in functional to digital interface ADHESIVE GASKET PLACEMENT seal as shown in Fig. 5. Apply the ANTI-TAMPERING LOCKS FIXING as shown in Fig. 6. Fit the anti-tampering locks Fig. 5 Fig.
  • Page 15 GENERAL DIRECTIONS FOR INSTALLATION In order to achieve the best results from the schematics described it is necessary to install only original VIDEX equipment, strictly keeping to the items indicated on each schematic and follow these General Directions for Installation: •...
  • Page 16 ESVK/6788 Series “2 wire Bus” videokit Art. 4800M Digital codelock module BUILT-IN RELAYS – BACK EMF PROTECTION The Art. 4800M includes selectable back EMF protection on the relays. The jumpers marked MOV (One jumper for each relay) are used to select the protection type. When using a fail secure lock with connections C & NO the jumper should be in the NO position. When using a fail open lock with connections C &...

  • Page 17: Art. 4800 - 4800M Digital Codelock Module

    ESVK/6788 Series “2 wire Bus” videokit Art. 4800M Digital codelock module ADHESIVE GASKET PLACEMENT seal as shown in Fig. 2. Apply the ANTI-TAMPERING LOCKS FIXING as shown in Fig. 3. Fit the anti-tampering locks Fig. 2 Fig. 3 CLEANING OF THE PLATE CONNECTION TERMINALS SIGNALS Use a clean and soft cloth.
  • Page 18 ESVK/6788 Series “2 wire Bus” videokit 4000 Series Surface and flush mounting door station installation EXAMPLE: INSTALLING A FOUR MODULE OUTDOOR STATION fig. 1 fig. 2 fig. 3 fig. 4 fig. 5 fig. 6 fig. 7 fig. 8 fig. 9 fig.
  • Page 19 ESVK/6788 Series “2 wire Bus” videokit 4000 Series Surface and flush mounting door station installation INSTALLING A SURFACE MOUNT DOOR STATION 1. Place the surface box against the wall (165-170cm between the top of the box and the floor level as shown in Fig. 1) and mark the fixing holes for the wall plugs and the hole for the cables (fig. 2).
  • Page 20 ESVK/6788 Series “2 wire Bus” videokit Art. 6788 7" hands free colour display digital videophone R03A(-2) 27mm 200mm PT3 PT2 1 2 3 6 7 8 1 2 3 4 Fig. 2 Fig. 1 DESCRIPTION LEGEND Surface mount hands free intelligent Videophone using 7” full Connection terminals colour active matrix LCD monitor for VX2300.

  • Page 21: Art. 6788 7" Hands Free Colour Display Digital Videophone

    ESVK/6788 Series “2 wire Bus” videokit Art. 6788 7" hands free colour display digital videophone PUSH BUTTONS Answer push button. On an incoming call, operation of this button allows the user to answer and converse with the visitor. The relevant LED will illuminate.
  • Page 22 ESVK/6788 Series “2 wire Bus” videokit Art. 6788 7" hands free colour display digital videophone PRIVACY DURATION • Keep pressed the button until the two LEDs are switched on. • Press the button for the number of times corresponding to the required privacy duration to set. Each time the button is pressed, the duration is increased by 15 minutes: i.e.
  • Page 23 ESVK/6788 Series “2 wire Bus” videokit Art. 6788 7" colour display videophone SLAVE SWITCH ON MODE - SW3.4 This set up concerns the answering mode of the video monitor when there is more than one unit (max 4) in the same apartment.
  • Page 24 ESVK/6788 Series “2 wire Bus” videokit 6700 Series Wall mounting instructions Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6 Fig. 7 1. In order to install the videophone, it is necessary to remove the cover, which contains all the electronics, from the base: then rotate clockwise until you listen a “CLICK!”.
  • Page 25 ESVK/6788 Series “2 wire Bus” videokit Art. 2321-2321/P Power supplies for VX2300 Art.2321 157,5 Fig. 1 Fig. 2 DESCRIPTION CONNECTION TERMINALS AND JUMPERS These two power supplies are specifically designed for the Mains input VX2300 digital system. The Art.  2321 can be used for systems ~230V with 1 entrance up to 20 users while the Art. 2321/P is for sys-...
  • Page 26 ESVK/6788 Series “2 wire Bus” videokit Art. 2322 Power supply converter from BUS line to 12 Vdc Art.2322 Fig. 1 Fig. 2 DESCRITPION When this unit is connected to the BUS line it generates a +12Vdc – 100mA power source. This unit can be used to supply peripher- als such as the Art. 4800 or Art. 4800M without the need for an additional power supply.
  • Page 27 ESVK/6788 Series “2 wire Bus” videokit Art. 125 Call expansion module DESCRITPION This module must be used in combination with speaker units Art. 4333 with firmware release 2.0 or higher. The module, in com- bination with standard 4000 series button expansion modules (Art. 4842, Art. 4843, Art. 4844 and Art. 4845), allows to add up to 5 call buttons to the call buttons built-in the speaker unit to reach a maximum of 7 call buttons.

  • Page 28: Art. 125 Call Expansion Module

    ESVK/6788 Series “2 wire Bus” videokit Art. 125 Call expansion module Connect to “PTE” terminal of Art. 4333 Connect to “GND” terminal ofArt. 4333 Black BALANCE Connect to “1C” terminal of Art. 4842, Art. 4843, Art. 4844 or Art. 4845 Connect to terminal “1” of the button expansion module Connect to terminal “2”...
  • Page 29 - 29 - 66550029-EN - V4.0 - 15/02/19...
  • Page 30 - 30 - 66550029-EN - V4.0 - 15/02/19...
  • Page 31 - 31 - 66550029-EN - V4.0 - 15/02/19...
  • Page 32 - 32 - 66550029-EN - V4.0 - 15/02/19...
  • Page 33 - 33 - 66550029-EN - V4.0 - 15/02/19...
  • Page 34 - 34 - 66550029-EN - V4.0 - 15/02/19...
  • Page 35 - 35 - 66550029-EN - V4.0 - 15/02/19...
  • Page 36 )power off then power on). 12Vac Title: Data creazione: Foglio 13/04/2017 Titolo: Data modifica: 13/04/2017 Videx Electronics S.p.A. Notes: Autore: Marco Rongoni Via del Lavoro 1, 63846 Monte Giberto )FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 esvk-67h-007.dwg www.videx.it - info@videx.it...
  • Page 37 - 37 - 66550029-EN - V4.0 - 15/02/19...
  • Page 38 - 38 - 66550029-EN - V4.0 - 15/02/19...
  • Page 39 DISPOSAL In accordance with the Legislative Decree no. 49 of 14 March 2014 “Implementation of the Directive 2012/19/EU on waste electrical and electronic equipment (WEEE)”. The crossed-out bin symbol on the equipment or on the packaging indicates that when the product reaches the end of its lifetime, it must be collected separately from mixed municipal waste.
  • Page 40 MANUFACTURER VIDEX ELECTRONICS S.P.A. FABBRICANTE Via del Lavoro, 1 FABRICANT 63846 Monte Giberto (FM) Italy FABRICANTE Tel (+39) 0734 631669 FABRIKANT Fax (+39) 0734 632475 ‫الشركة المص ن ِّ عة‬ www.videx.it - info@videx.it CUSTOMER SUPPORT VIDEX ELECTRONICS S.P.A. UK Customers only: SUPPORTO CLIENTI www.videx.it - technical@videx.it...
