STANDARD LEDs BEHAVIOUR
N° LED behaviour
1 GREEN ON
2 GREEN BLINKING
3 RED GREEN BLINKING
4 RED GREEN ON
DIMENSIONS [mm]
The performances stated in this sheet can be modifi ed without any prior notice
The actuator arrived at the extreme point of the stroke read
The actuator arrived at the intermediate point of the stroke read
The actuator is reading the stroke or it is going to initial position
Manual control ON, the actuators ignores the control signal.
ATTENTION! The electronic board is electrically supplied
194
194
1 Issue rev. d
st
Actuator status
122
122
01/2016 DBL394e Page 7
