1045CFV Clearview Front Vintage Iron
Approved for use with Valor H3 1000 Models fitted with
1035BPB, 1035BPB-RC or 1036BPB-RC Backing Plates
DANGER
!
A barrier designed to reduce the risk of burns from the hot
viewing glass is provided with this appliance and must be
installed for the protection of children and other at-risk
individuals.
The 1045CFV Clearview Front is intended to be used
on Valor heaters model 1000 fi tted with either the
1035BPB, 1035BPB-RC or 1036BPB-RC Backing Plates.
1045CFV Clearview Front Dimensions
1035BPB Backing Plate outline
36-13/16" [935 mm]
4007389-03
© Copyright Miles Industries Ltd., 2020
H3 Series
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
INSTALLER: Leave this
manual with the appliance.
CONSUMER: Retain
this manual for future
reference.
Mounting of this front does not aff ect clearances or
other specifi cations listed in the heater installation
manual.
1035BPB-RC Backing Plate outline
1036BPB-RC Backing Plate outline
36-13/16" [935 mm]
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1045CFV and is the answer not in the manual?

Questions and answers

Summary of Contents for Valor 1045CFV

  • Page 1 INSTALLATION MANUAL H3 Series 1045CFV Clearview Front Vintage Iron Approved for use with Valor H3 1000 Models fitted with 1035BPB, 1035BPB-RC or 1036BPB-RC Backing Plates DANGER INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future HOT GLASS WILL reference.
  • Page 2 Installation After completion of appliance and backing plate installation, hook the front to the backing plate. 1045CFV Clearview Front installed on a 1035BPB-RC Repair Parts List Description Part Numbers Clearview front panel 4007123V Top retainer 4007124AZ Right side bracket 4007126AZ...
  • Page 3 GUIDE D’INSTALLATION Série H3 Bordures Clearview fer antique 1045CFV Certifiées pour usage avec foyers Valor H3 1000 installés avec Plaques de finition 1035BPB, 1035BPB-RC ou 1036BPB-RC DANGER INSTALLATEUR : Laissez cette notice avec l’appareil. CONSOMMATEUR : Conservez cette notice pour VITRE CHAUDE - RISQUE consultation ultérieure.
  • Page 4 Installation Après l’installation du foyer et de la plaque de fi nition choisie, accrochez la bordure à la plaque de fi nition. Bordure Clearview 1045CFV installée avec une Plaque 1035BPB-RC Pièces Numéros de Description pièces Façade Clearview 4007123V Montant du haut...
