Valor H3 Series Installation Manual

INSTALLATION MANUAL
1070RGL Refl ective Glass Liner Set
For use with Valor H3 Model1000 Fireplaces ONLY
Kit Content
•
4007203—LH glass panel
•
4007188—Top ceramic panel
•
4007205—Rear glass panel
•
4007204—RH glass panel
•
4007202—LH + RH ceramic fi ller panels (2)
•
4007201—Rear ceramic fi ller panel
•
4004981—Sheet metal clips (4)
Unpack all cartons carefully, with special care for the
glass panels.
To achieve the intended eff ect, the panels should be
installed so the smooth side is visible.
LH Glass Panel
LH Filler Panel
4007577-01
© 2019, Miles Industries Ltd. All rights reserved.
H3 Series
Rear Glass Panel
Note: This kit must be installed or serviced
by a qualifi ed installer, service agency
or gas supplier. These instructions are
to be used in conjunction with the main
installation instructions for the above
listed models.
WARNING: If these instructions are not
followed exactly, a fi re or explosion may
result causing property damage, personal
injury or loss of life.
Top Panel
Rear Filler Panel
Side Panel
Clip x4
RH Glass Panel
RH Filler Panel
1
