INSTALLATION MANUAL

1100MNGKV2 / 1100MPGKV2 Gas Conversion

For Valor 1100M ﬁ replaces ONLY

This appliance is certified for use from 0–4500 feet. For

altitudes above 4500 feet, see local codes.

Kit Contents

1 Pilot injector

1 Main burner injector

1 Set of conversion labels

1 Minimum rate by-pass screw

1 PSE Pilot Assembly 36" + instructions

1 Pilot gasket

Tools Required

• Wrenches, to disconnect gas line

• Phillips (+) screwdriver

• Small (jewelers size) flat blade screwdriver, to set

pressure

• Small flat blade screwdriver, to release pressure tap

on valve

• Needle nose pliers, to remove bypass screw

• Allen key, 5/32", to change bypass screw

• Wrench, 7/16", to remove pilot hood and injector

• Socket wrench, 7/16", with extension to change main

burner injector

• Manometer, to set pressure

Speciﬁ cations

Model

Gas

Altitude (Ft.)*

Input Maximum (Btu/h)

Input Minimum (Btu/h)

Manifold Pressure (in w.c.)

Minimum Supply Pressure (in w.c.)

Maximum Supply Pressure (in w.c.)

Main Burner Injector Marking

PSE Pilot Injector Marking

Min. Rate By-Pass Screw

4009718-01

H5 Series

1100MN

1100MP

Natural

Propane

0-4,500 feet

30,000

16,000

3.5"

11"

10"

14"

36 DMS

51 DMS

BL22N

BL14LP

185

125

WARNING

This conversion kit shall be installed by

a qualified service agency in accordance

with the manufacturer's instructions and

all applicable codes and requirements

of the authority having jurisdiction. If

the information in these instructions is

not followed exactly, a fire, explosion

or production of carbon monoxide may

result causing property damage, personal

injury or loss of life. The qualified service

agency is responsible for the proper

installation of this kit. The installation

is not proper and complete until the

operation of the converted appliance is

checked as specified in the manufacturer's

instructions supplied with the kit.

Use this manual in conjunction with the

installation manual supplied with the

appliance.

General Notes Regarding Conversion

The conversion may be done before or after the

appliance is installed into the cavity. However, the gas

must be connected to set the manifold pressure.

Need help?

Do you have a question about the H5 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Valor H5 Series

Page 1 INSTALLATION MANUAL H5 Series 1100MNGKV2 / 1100MPGKV2 Gas Conversion For Valor 1100M ﬁ replaces ONLY This appliance is certified for use from 0–4500 feet. For altitudes above 4500 feet, see local codes. WARNING Kit Contents This conversion kit shall be installed by...
Page 2 Prepare the appliance 6. Remove the burner module by undoing 12 screws (including those holding down the air deflector). See your Installation Manual for help with these steps. Remove the air deflector, and then the module by 1. If the fireplace is already installed, remove the lifting forward and then up.
Page 3 Replace the pilot injector or pilot assembly* 4. Replace with the appropriate pilot injector—see Specifications table on page 1. Drop in the new *In some units, the replacement pilot injector will not injector, flared side down. permit the pilot hood to be refastened to the proper orientation.
Page 4 3. Locate and remove the by-pass screw. It may be 6. Reinstall burner to burner module. Gently insert covered by a sticker. burner tube into aeration block, and drop onto Note that the by-pass screw may require either a brackets on burner module. Screw in 2 screws. flat head screwdriver or an Allen key depending on its type.
Page 5 3. Replace any remaining doors, covers, and trim. 2. Reinstall the burner cover (4 screws). Designed and Manufactured by / for Miles Industries Ltd. 190 – 2255 Dollarton Highway, North Vancouver, B.C., CANADA V7H 3B1 Tel. 604-984-3496 Fax 604-984-0246 www.valorﬁ replaces.com...
Page 6: Guide D'installation
GUIDE D’INSTALLATION Série H5 Trousses de conversion de gaz 1100MNGK et 1100MPGK pour foyers Valor 1100M SEULEMENT Cet appareil est homologué pour utilisation de 0 à 4 500 pieds. Pour altitudes au-dessus de 4 500 pieds, AVERTISSEMENT consultez la règlementation locale.
Page 7 Préparez l’appareil 6. Enlevez le module du brûleur et déflecteur d’air en dévissant les 12 vis les retenant. Enlevez le 1. Si le foyer est déjà installé, enlevez le pare-étincelles, déflecteur puis soulevez le module vers l’avant puis les portes des côtés, la plinthe, la fenêtre, le lit de vers le haut pour le sortir de la boîte de foyer.
Page 8 Remplacez l’injecteur de veilleuse ou la 4. Remplacez l’injecteur de veilleuse avec l’injecteur approprié—voir le tableau des Spécifications à la veilleuse* page 6. Mettez le nouvel injecteur en place, bout *Dans certains cas, le remplacement de l’injecteur de la évasé vers le bas. veilleuse ne permettra pas de réinstaller le capuchon de la veilleuse dans l’orientation appropriée.
Page 9 3. Localisez et enlevez la vis d’indice minimum sur la 6. Réinstallez le brûleur sur le module. Insérez d’abord soupape. La vis peut être couverte par un le tube du brûleur dans le bloc d’aération puis posez autocollant. le brûleur sur ses point de fixation. Fixez-le à ses Notez que la vis peut devoir être enlevée avec un supports (2 vis).
Page 10 2. Allumez l’appareil et tournez le bouton de contrôle à 3. Réinstallez les panneaux intérieurs, le lit de pleine capacité. combustion et la fenêtre. Consultez le guide d’installation du foyer pour tous les détails 3. Réglez la vis d’ajustement de pression sur la soup- concernant l’installation de ces pièces.
