Medium UPM

1. Introduction

Medium UPM - EU range

This data booklet applies to the Grundfos Medium UPM pump range.
Type
UPMM xx-95
UPMM xx-95 AUTO
UPML xx-105
UPML xx-105 LIN
UPML xx-105 AUTO
SOLAR PML xx-145
UPMXL xx-125
UPMXL xx-125 LIN
UPMXL xx-125 AUTO
UPMXXL xx-120
UPMXXL xx-120 AUTO

Applications

In a modern heating, cooling and domestic hot water
supply system there are different circuits in which
Medium UPM pumps in different versions can be
placed. A differentiation must be made between the
heating (or cooling) production and the distribution.
On the production side there are some applications
where pumps are used in primary or internal circuits
e.g. for geothermal or solar thermal brine circuits.
The distribution side is often split into two circuits - a
primary and a secondary circuit - in order to keep the
flow and temperature independent from each other. A
heat exchanger, a hydraulic separator or a buffer tank
can be used for this separation.
Application
Gas or oil-fired space and combination heaters
Solid fuel heaters
Heat pumps (brine side)
Heat production or heat
Heat pumps (heating side)
transmission side
Mini combined heat and power cogeneration
Thermal solar system (collector side)
District heating systems with heat exchanger
Space heating systems
Space heating and cooling systems
Heat distribution side Domestic hot water generation (heating side)
Domestic hot water generation (DW side)
Domestic hot water recirculation
P1 max. Control
PWM A
100 W
AUTO
PWM A
LIN bus
140 W
AUTO
140 W PWM C
PWM A
180 W LIN bus
AUTO
PWM A
180 W
AUTO
For some heating generators (e.g. condensing boilers,
heat pumps or district heating) it is important to keep
the return temperature as low as possible. Therefore it
is necessary to keep the right balance between flow in
primary and secondary circuits. Without separator, the
primary pump creates a differential pressure in the
secondary circuits. A generator effect can happen in
the secondary pump, from which Medium UPM pumps
are protected.
The primary pump is mostly integrated into the heating
appliance and controlled via a control signal (e.g.
PWM or BUS) to ensure the optimum operation of the
boiler, for instance.
● ● ●
● ● ●
● ● ●
● ● ●
● ● ●
● ● ●
● ● ●
● ● ●
● ● ●
● ●
● ●
Recommended pump type
UPMM/UPML/UPMXL/UPMXXL PWM/LIN
UPMM/UPML/UPMXL/UPMXXL AUTO
UPMM/UPML/UPMXL/UPMXXL PWM/LIN
UPMM/UPML/UPMXL/UPMXXL PWM/LIN
UPMM/UPML/UPMXL/UPMXXL PWM/LIN
SOLAR PML
UPMM/UPML/UPMXL/UPMXXL PWM/LIN
UPMM/UPML/UPMXL/UPMXXL AUTO
UPMM/UPML/UPMXL/UPMXXL AUTO
UPMM/UPML/UPMXL/UPMXXL PWM/LIN
UPMM/UPML/UPMXL AUTO N
UPMM/UPML/UPMXL AUTO N
