Grundfos Medium UPM Series Data Booklet page 40

13
SOLAR PML 15-145 130, 25-145 130, 25-145 180 (N), 32-145 180 (GFJNB)
p H
[kPa] [m]
14
120
12
100
10
80
8
60
6
40
4
20
2
0 0
0.0
0.0
P1
[W]
140
120
100
80
60
40
20
0
0.0
Electrical data, 1 x 230 V, 50/60 Hz
Speed
Min.
Max.
Dimensions
B1
B3
Pump type
SOLAR PML 15-145 130
SOLAR PML 25-145 130
SOLAR PML 25-145 (N) 180
SOLAR PML 32-145 180
Technical data
System pressure:
Minimum inlet pressure:
Liquid temperature:
Motor protection:
40
0.5 1.0 1.5 2.0 2.5 3.0
0.2 0.4 0.6 0.8
0.5 1.0 1.5 2.0 2.5 3.0
P [W] I
1
3
140
B2
L1 L2 L3
130 65 45
130 65 45
180 90 45
180 90 45
Max. 1.0 MPa (10 bar)
0.01 MPa (0.10 bar) at 95 °C liquid temperature
-10 °C to +95 °C (TF 95)
Overload protection
3.5 4.0 4.5 5.0
Q [m³/h]
1.0 1.2 1.4 Q [l/s]
3.5 4.0 4.5 5.0 Q [m³/h]
[A]
1/1
0.04
1.1
H1 H2
H3
Dimensions [mm]
L4 B1 B2 B3
65 94 50 52
65 94 50 52
65 94 50 52
65 94 50 52
High Efficiency
EEI ≤ 0.23 Part 3
≤ 65 W
P
L, avg
Connections
H1 H2 H3
38 104 82 G 1
38 104 82 G 1 1/2
38 104 82 G 1 1/2
38 104 82 G 2
Enclosure class: IPX2D
Insulation class: H
Equipment class: I
Approval and marking: VDE, CE
Net weight
[kg]
2.3
2.4
2.5
2.7
