Grundfos Medium UPM Series Data Booklet page 43

UPMXXL 25-120 180, 32-120 180 (GFJOB)
p H
[kPa] [m]
120
12
100
10
80
8
60
6
40
4
20
2
0 0
0 1 2
0.0 0.5
P1
[W]
200
160
120
80
40
0
0 1 2
Electrical data, 1 x 230 V, 50/60 Hz
P
Speed
1
Min. 3
Max. 180
Dimensions
B1
B3
Pump type
UPMXXL 25-120 180
UPMXXL 32-120 180
Technical data
System pressure: Max. 1.0 MPa (10 bar)
Minimum inlet pressure: 0.01 MPa (0.10 bar) at 95 °C liquid temperature
Liquid temperature: -10 °C to +95 °C (TF 95)
Motor protection: Overload protection
3 4 5 6 7
1.0 1.5 2.0
3 4 5 6 7
[W] I [A]
1/1
0.04
1.42
B2 H1
Dimensions [mm]
L1 L2 L3 L4 B1
180 90 45 65 117
180 90 45 65 117
8 Q [m³/h]
2.5
Q [l/s]
8 Q [m³/h]
H2
H3
B2 B3 H1 H2
50 75 55 104
50 75 55 104
Enclosure class:
Insulation class:
Equipment class:
Approval and marking:
High Efficiency
EEI ≤ 0.23 Part 2
≤ 94 W
P
L, avg
Net weight
Connections
[kg]
H3
82 G 1 1/2 3.2
82 G 2 3.4
IPX2D
H
I
VDE, CE
13
43
