Summary of Contents for AXIOMTEK Agent200
- Page 1 Agent200 Robust Din-rail Fanless Embedded System Hardware User’s Manual...
- Page 2 Axiomtek does not make any commitment to update the information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice.
-
Page 3: Safety Precautions
Disconnect the power cord from the Agent200 before making any installation. Be sure both the system and the external devices are turned OFF. Sudden surge of power could ruin sensitive components. Make sure the Agent200 is properly grounded. Make sure the voltage of the power source is correct before connecting the equipment to the power outlet. -
Page 4: Classification
Classification Degree of production against electric shock: not classified Equipment not suitable for use in the presence of a flammable anesthetic mixture with air or with oxygen or nitros oxide. Mode of operation: Continuous Type of protection against electric shock: Class I equ ipment General Cleaning Tips You may need to take the following precautions before you begin to clean the computer. -
Page 5: Cleaning Tools
Cleaning Tools Although many companies have created products to help improve the process of cleaning your computer and peripherals users can also use household items to clean their computers and peripherals. Below is a listing of items you may need or want to use while cleaning your computer or computer peripherals. -
Page 6: Scrap Computer Recycling
Trademarks Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd. IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation. ®... -
Page 7: Table Of Contents
Table of Contents Safety Precautions ..................iii Classification....................iv General Cleaning Tips ................. iv Cleaning Tools ....................v Scrap Computer Recycling ................. vi SECTION 1 INTRODUCTION ............1 General Description ..............1 System Specifications ............... 2 1.2.1 CPU ........................2 1.2.2 System Memory .................... - Page 8 This page is intentionally left blank. viii...
-
Page 9: Section 1 Introduction
+70°C for using in extreme operating environment and industrial automation applications. The Agent200 features 1 RS-232/422/485 serial port with console debug port, 1 CAN bus 1 LAN, 1 DIO Port (4-In/4-Out), 1 USB, 1 eMMC of 4GB onboard and 1 microSD socket for easy storage expansion and access in a compact, industrial-strength robust case. -
Page 10: System Specifications
Agent200 User’s Manual Storage: Supports one eMMC of 4GB onboard (for boot disk) Supports one micro SD Card (easy-to-access, for store only) 1 power path with terminal block and 9–48VDC Din-rail mounting System Specifications 1.2.1 ® ®... -
Page 11: Com
Agent200 User’s Manual 1.2.11 DB9 Pin define non isolation protection RS232/RS422/RS485 (COM1) COM 1 with TX/RX/RTS/CTS signals RS-232/422/485 interface selected by software COM1 RS-232 RS-422 RS-485 Data- Data+ Ground Ground Ground 1.2.12 CAN bus (Optional) ... -
Page 12: Power
Agent200 User’s Manual 1.2.13 Power DC input range 9~48V DC Input has UVP/Reverse protection. UVP (Under voltage protection) Reserve protection Power consumption 9~48VDC, 0.46A~0.11A 0.46A@9V 0.35A@12V 0.11A@48V DC Terminal Block DC Signal Name... - Page 13 Agent200 User’s Manual DIO 4-IN/4-OUT of TB10 Female Agent200 DIO Terminal Block TB18 Pin No. Signal name Meaning COM+ Plus Common for DIO Digital Input Digital Output COM- Minus Common for DIO Introduction...
- Page 14 Agent200 User’s Manual DIO operation schematic diagram Input Circuit Output Circuit Introduction...
- Page 15 Agent200 User’s Manual Digital Input W iring Dry Contact Wet Contact If you are using wet contacts, you must connect COM to power. Note Digital Output W iring Introduction...
-
Page 16: System Led
Agent200 User’s Manual 1.2.15 System LED LED Name Description Color The LED helps users judge whether boot is finished and the OS can work normally or not. When the boot has finished system configuration, the LED will turn ON. Status... -
Page 17: Wireless (3G/Gprs Or Wifi)
Agent200 User’s Manual 1.2.16 Wireless (3G/GPRS or WiFi) 1 x Mini card socket 0 (supports USB interface) with 1 x Standard SIM Card Socket by outside 1 x Mini card socket 1 (supports USB interface) Support WiFi or 3G/4G 1.2.17... -
Page 18: Dimensions
Agent200 User’s Manual 1.2.22 Dimensions 31mm(W) x 100mm(D) x 125mm(H) 1.2.23 System I/O Outlet 1 9-pin D-Sub male connectors (COM1 port or Console Port ) 1 DIP Switch COM1 or Console Port Select 1 10/100Mbps Ethernets with magnetic isolation protection ... -
Page 19: Dimensions
Agent200 User’s Manual Dimensions The following diagrams show the dimensions and outlines of the Agent200 Introduction... -
Page 20: I/O Outlets
Agent200 User’s Manual I/O Outlets The following figures help you locate the I/O outlets on the front, top and bottom of the Agent200. Front View Top View Introduction... - Page 21 Agent200 User’s Manual Bottom View Introduction...
-
Page 22: Packing List
Din-rail Kit x1 Power 3pin terminal block x 1 DIO 10pin terminal block x 1 Please download the latest BSP or the latest Web_AP for Agent200 from Axiomtek’s website as below list if you have the demand. Note https://www.axiomtek.com/Default.aspx?MenuId=Products&FunctionId=Downloa dSearch Please contact an Axiomtek distributor if any of the above-mentioned items is damaged or missing. -
Page 23: Section 2 Hardware Installation
Agent200 User’s Manual SECTION 2 HARDWARE INSTALLATION Installing Din-rail Mounting The Agent200 provides a Din-rail mount that customers can install as below: Prepare the Din-rail mount assembling components ( Four screws and a bracket) ready. Hardware Installation...
