Important Safety Instructions - Mover
PERMANENT MAGNETIC FIELD
CLASS3
WIRING
VIBRATIONS
DO NOT DROP THE MOVER
CLASS3
WIRING
USE THE MOVER IN DRY
ENVIRONMENT
CLASS3
WIRING
DO NOT TRY TO MODIFY THE MOVER
CLASS3
WIRING
IN ANY PART
CLASS3
STORAGE
WIRING
AVOID EXCESSIVE HEAT
CLASS3
WIRING
CLASS3
WIRING

System Specifications

MeMo Amplifier:
Dimensions: L 27.4 cm x W 21.0 cm x H 3.7 cm.
Weight: 2.31 kg.
Peak Power Output: 250 W @ 4 Ohm.
Average Power Output: 40 W @ 4 Ohm.
Signal Processing with sub-harmonics enhancements, optimized for Mover applications.
Preset selector:
• Music preset - Ideal for every multimedia and music content!
• Cinema preset - Ultra-low frequency enhanced for the best movie experience!
• Gaming preset - Dive yourself inside your favorite game and play with the fourth dimension!
Warranty (*): 2 years + 1 after product registration.
(*) Standard Warranty is 2 years. Amplifier warranty will be extended of one year if the product will be registered
Mover transducer:
Dimensions: 90 mm x 90 mm x 90 mm .
Weight: 2.44 kg.
Piston weight: 1.2 kg.
Magnet type: 0.28 kg Neodymium magnet, grade N50.
Frequency Response: 5 – 500 Hz.
Nominal Impedance: 4 Ohm.
Nominal Bl: 32 Tm
Warranty: 2 years
For any query reach out to us through our website www.powersoft.com.
External magnetic field: 1.5 mT @ 100 mm from the shell.
Do not use electronic devices and magnetic cards close to the Mover.
Do not place the Mover in proximity to tube TV/Video monitors.
Be careful when using tools around the Mover.
Be careful when handling more than one Mover at a time outside boxes: take Movers at least 80 mm far one
from each other.
System exposes human body to mechanical vibrations
Impacts can damage the Mover: warranty will be void if signs of impacts will be detected.
Do not expose the Mover to liquid spray.
Do not immerge the Mover in liquids.
Never try to open or modify the Mover for any reason!
- Risk of serious injury.
- Risk to damaging the unit.
- Warranty void if open or altered.
When not in use, keep the Mover adequately protected, in a dry place. Use its original package to store the
Mover.
Do not expose Movers to excessive heat, over than 60 °C (140 F) environmental temperature.
Durability and performances of the units can diminish if they are used in excessive warm environment.
