TOPP ACK4S Series Installation And Use Instructions Manual

Chain actuator for window automation
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLATION AND USE INSTRUCTIONS
PATENTED
BEFORE INSTALLING AND USING THE ACTUATOR, IT IS
COMPULSORY FOR THE INSTALLER AND THE USER TO READ
AND UNDERSTAND THIS MANUAL IN ALL ITS PARTS.
THIS MANUAL IS INTEGRAL PART OF THE ACTUATOR
AND MUST BE PRESERVED FOR FUTURE REFERENCE
CHAIN ACTUATOR FOR
WINDOW AUTOMATION
UNTIL DEMOLITION OF THE SAME.
original instructions
ACK4S
COD. 0P5301
VER.0.0 REV.06.19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACK4S Series and is the answer not in the manual?

Questions and answers

Related Manuals for TOPP ACK4S Series

Summary of Contents for TOPP ACK4S Series

  • Page 1 original instructions INSTALLATION AND USE INSTRUCTIONS CHAIN ACTUATOR FOR ACK4S WINDOW AUTOMATION PATENTED COD. 0P5301 VER.0.0 REV.06.19 BEFORE INSTALLING AND USING THE ACTUATOR, IT IS COMPULSORY FOR THE INSTALLER AND THE USER TO READ AND UNDERSTAND THIS MANUAL IN ALL ITS PARTS. THIS MANUAL IS INTEGRAL PART OF THE ACTUATOR AND MUST BE PRESERVED FOR FUTURE REFERENCE UNTIL DEMOLITION OF THE SAME.

  • Page 3: Table Of Contents

    ACK4S INDEX 1- EC DECLARATION OF INCORPORATION OF PARTLY COMPLETED MACHINERY ...........................page 04 2- GENERAL REMARKS 2.1- General instructions ..................page 05 2.2- Installer and user ....................page 05 2.3- Technical assistance ..................page 05 2.4- Reserved rights ....................page 06 2.5- Description of personnel ...................page 06 3- TECHNICAL DESCRIPTION 3.1- Rating plate and "CE"...
  • Page 4 36066 Sandrigo (VI) Italia herewith declares that the person authorised to compile the technical file is Name: Bettiati Roberto - Topp S.r.l. Address: via Galvani,59 36066 Sandrigo (VI) and that to the partly completed machinery CHAIN ACTUATOR FOR WINDOW AUTOMATION...

  • Page 5: General Instructions

    ACK4S GENERAL REMARKS -2 2.1- GENERAL INSTRUCTIONS BEFORE INSTALLING AND USING THE ACTUATOR, IT IS COMPULSORY THAT THE INSTALLER AND THE USER CAREFULLY READ AND UNDERSTAND THIS MANUAL IN ALL ITS PARTS. THIS MANUAL IS INTEGRAL PART OF THE ACTUATOR AND MUST COMPULSORILY BE PRESERVED FOR FUTURE REFERENCE.

  • Page 6: 2- General Remarks

    2- GENERAL REMARKS ACK4S 2.4- RESERVED RIGHTS The reserved rights on this manual "Installation and use instructions" remain property of the Manufacturer. Each information herein contained (text, drawings, diagrams, etc.) is reserved. None part of this manual can be reproduced and disclosed (totally or partially) by any reproduction means (photocopies, microfilms or other) without written authorization of the Manufacturer.

  • Page 7: Rating Plate And "Ce" Marking

    ACK4S TECHNICAL DESCRIPTION -3 3.1- RATING PLATE AND "CE" MARKING The "CE" marking certifies the compliance of the machine with the essential safety and health requirements foreseen by the product European Directives. The rating plate is an adhesive plate in polyester, silk-screen printed in black, having the following size: L= 50 mm - H= 36 mm.

  • Page 8: 3- Technical Description

    3- TECHNICAL DESCRIPTION ACK4S 3.2- DENOMINATION OF THE COMPONENTS AND DIMENSIONS Fig. 1 Dimensions in mm LEGEND: 1) Power supply cable 2) Support heads 3) Support 4) Opening stroke adjustment on both sides 5) Actuator 6) Chain pin 7) Bracket for bottom hung opening 8) Window frame connection bracket INSTALLATION AND USE ISTRUCTIONS...

  • Page 9: Technical Data

    ACK4S TECHNICAL DESCRIPTION -3 3.3- TECHNICAL DATA Tab. 1 contains the technical data characterising the actuators. Tab. 1 ACK4S/230V ACK4S/24V POWER SUPPLY VOLTAGE 230 V ~ 50 Hz 24 V ± 10% ABSORBED CURRENT 0,20 A 1,0 A ABSORBED POWER WITH LOAD 32 W 24 W PROTECTION AGAINST ELECTRIC SHOCKS...

  • Page 10: Destination Of Use

    MEANS OF A CONTROL DEVICE, THE OPENING AND CLOSING OF TOP HUNG WINDOWS, BOTTOM HUNG WINDOWS, PIVOT WINDOWS, AND SKYLIGHTS. The ACK4S Chain actuator is equipped with the latest TOPP system for the coordinated synchronization of the chain movement. The electronic speed control is fully automatic and requires no external control unit;...

  • Page 11: Use Limits

    ACK4S TECHNICAL DESCRIPTION -3 3.6- USE LIMITS The actuator has been designed and manufactured exclusively for the destination of use given in par .3.5, therefore, any other type of use is strictly forbidden in order to assure in any moment the safety of the installer and of the user, as well as the efficiency of the actuator itself.
  • Page 12 3- TECHNICAL DESCRIPTION ACK4S Fig.4 INSTALLATION AND USE ISTRUCTIONS...

  • Page 13: General Instructions

    ACK4S SAFETY -4 4.1- GENERAL INSTRUCTIONS OPERATORS MUST BE INFORMED OF ACCIDENT RISKS, SAFETY DEVICES AND THE GENERAL ACCIDENT PREVENTION REGULATIONS ESTABLISHED BY INTERNATIONAL DIRECTIVES AND BY THE LAW IN FORCE IN THE COUNTRY OF U S E. A L L O P E R ATO R S M U S T S T R I C T LY C O M P LY W I T H T H E A C C I D E N T PREVENTION REGULATIONS IN FORCE IN THE COUNTRY OF USE.

  • Page 14: Safety Plates

    4- SAFETY ACK4S 1) Insulation of live parts by means of a plastic material body; 2) Enclosure with suitable protection degree; 3) Only for the mod. ACK4S/230V provided with protection against electric shocks: Protection of passive type given by the use of components with double insulation, also called components of class II or with equivalent insulation.

  • Page 15: General Instructions

    ACK4S INSTALLATION -5 5.1- GENERAL INSTRUCTIONS THE ACTUATOR INSTALLATION CAN BE PERFORMED EXCLUSIVELY BY COMPETENT AND QUALIFIED TECHNICAL PERSONNEL SATISFYING THE PROFESSIONAL AND TECHNICAL REQUIREMENTS FORESEEN BY THE LAWS IN FORCE IN THE COUNTRY OF INSTALLATION. THE ACTUATOR PERFORMANCE MUST BE SUFFICIENT TO ASSURE THE CORRECT MOVEMENT OF THE WINDOW.

  • Page 16: Top Hung Windows

    5- IINSTALLATION ACK4S Fig. 6 5.2- TOP HUNG WINDOWS (Fig. 6 and 13 ÷ 23) 1) Open the package (par. 3.7) and extract the various components; 2) Fig. 14- With a pencil draw the centre line "X" of the window frame; 3) Fig.

  • Page 17: Bottom Hung Windows

    ACK4S INSTALLATION -5 Fig. 7 12) Fig.20a- Unscrew and remove the screw and washer mounted at the factory on the chain ending"TC"; Fig. 21- Mount the nut "D2" on the hole head screw "V3" and then it on the chain ending "TC";...
  • Page 18 5- INSTALLATION ACK4S 6) With a suitable drill, create on the window frame holes given on the adhesive template "DV"; 7) Fig. 29- Mount the support "SA" on the fix window frame with the screws "V2"; check the perfect horizontal and vertical alignment with the window frame; 8) Mount the bracket "S2"...

  • Page 19: Electric Connections

    ACK4S INSTALLATION -5 5.4- ELECTRIC CONNECTIONS (Wiring diagram) THE ELECTRIC CONNECTION OF THE ACTUATOR CAN BE PERFORMED ONLY BY COMPETENT AND QUALIFIED TECHNICAL PERSONNEL SATISFYING THE TECHNICAL AND PROFESSIONAL REQUIREMENTS FORESEEN BY THE LAW IN FORCE IN THE COUNTRY OF INSTALLATION ISSUING TO THE CUSTOMER A DECLARATION OF CONFORMITY FOR THE CONNECTION AND/OR THE PLANT PERFORMED.

  • Page 20: Control Devices

    Bipolar switch button with central OFF position, with biased-off switch; 2) OPTIONAL: CONTROL AND FEEDING UNIT: TOPP Microprocessor control units (e.g.: Mod. TF44, etc.) controlling the single actuator (ACK4S/230V) or more than one actuator simultaneously (ACK4S/230V) or by means of one or more manual pushbuttons, an infrared remote control or a 433 Mhz radio control.

  • Page 21: Emergency Procedures

    ACK4S INSTALLATION -5 5.6- EMERGENCY PROCEDURES Should it be necessary to open the window manually due to power supply failure or mechanism block, follow these instructions: BEFORE PERFORMING ANY TYPE OF INTERVENTION ON THE ACTUATOR AND ON THE WINDOW, IT IS COMPULSORY TO DISCONNECT THE POWER SUPPLY OF THE ACTUATOR AND TO PUT ON "0"...

  • Page 22: 6- Use And Operation

    RECOMMEND CARRYING OUT PERIODICAL MAINTENANCE ON IT, AS INDICATED IN PAR. 7.1 OF THIS MANUAL. TOPP INFORMS THE USER THAT, IN ACCORDANCE WITH ART. 8 OF MINISTERIAL DECREE NO. 38 OF 22.1.2008, THE OWNER OF THE SYSTEM IS RESPONSIBLE FOR...

  • Page 23: Smart Reset System (Sai)

    This maintenance may be done either by TOPP, in accordance with a specific agreement made with the user, or by the installation technician or by other competent and qualified technical personnel in possession of all legal requirements.

  • Page 24: 9- Spare Parts And Accessories Upon Request

    8- DEMOLITION ACK4S 8.1- GENERAL INSTRUCTIONS THE DEMOLITION OF THE ACTUATOR MUST OCCUR IN COMPLIANCE WITH THE LAWS IN FORCE ON ENVIRONMENT PROTECTION. DIFFERENTIATE THE PARTS MAKING UP THE ACTUATOR ACCORDING TO THEIR DIFFERENT MATERIAL TYPE (PLASTIC, ALUMINIUM, ETC.). 9- SPARE PARTS AND ACCESSORIES UPON REQUEST ACK4S 9.1- GENERAL INSTRUCTIONS THE USE OF "NON-ORIGINAL"...
  • Page 25 ACK4S DRAWINGS FOR INSTALLATION Tab. 2 Stroke H (*) APPLICATION BRACKETS Wing Frame Wing Frame Wing Frame Wing Frame Frame Wing Frame Wing Minimum window height Distance from the opening edge of the window to the axis of rotation of the window INSTALLATION AND USE ISTRUCTIONS...
  • Page 26 DRAWINGS FOR INSTALLATION ACK4S Fig. 11 VERTICAL MOUNTING BRACKET (COD. 3A1380-81-82) WING FRAME OVERLAPPED PART “D” MUST BE LOWER 50mm SINGLE SWIVEL BRACKET (COD. 1A1665-66-67) 58.5 22.3 54.4 45.5 FRAME WING 106.5±4 OVERLAPPED PART “D” MUST BE LOWER 50mm DISTANCE MUST BE THE SAME FOR ACTUATORS ON THE SAME WINDOW THE FIXING POSITION (A) HAS TO BE VERIFIED AND EVALUATED ACCORDING TO THE PROFILE/WIDTH OF THE WING/FRAME AND OF THE WINDOW LIGHT.
  • Page 27 ACK4S DRAWINGS FOR INSTALLATION Fig. 12 SMALL SWIVEL BRACKET (COD. 3A1396-97-98-99) WING Make sure that the M6 nut is tightly fastened M6 nut FRAME OVERLAPPED PART “D” MUST BE LOWER 50mm BIG SWIVEL BRACKET (COD.3A1391-92-93-94) OVERLAPPED PART “D” MUST BE LOWER 50mm WING M6 nut FRAME...
  • Page 28 ACK4S INSTALLATION ON TOP HUNG WINDOWS Fig. 13 OVERLAPPED PART “D” MUST BE LOWER 50mm 0÷50mm Wing 45.5 Frame 27.5 55.2 96.7 INSTALLATION AND USE ISTRUCTIONS...
  • Page 29 ACK4S INSTALLATION ON TOP HUNG WINDOWS Fig. 14 Fig. 15 T1 T2 Fig. 16 Fig. 17 Fig. 18 INSTALLATION AND USE ISTRUCTIONS...
  • Page 30 ACK4S INSTALLATION ON TOP HUNG WINDOWS Fig. 20 Fig. 19 CAUTION: both must have the same stroke in tandem installations Fig. 20a Fig. 21 Fig. 22 Fig. 23 INSTALLATION AND USE ISTRUCTIONS...
  • Page 31 ACK4S INSTALLATION ON BOTTOM HUNG WINDOWS Fig. 24 96.3 55.2 27.5 0÷5mm APPLICATION 1 T1 and T2 head downwards Frame OVERLAPPED PART “D” MUST BE LOWER 50mm 105÷110 Wing DISTANCE MUST BE THE SAME FOR ACTUATORS ON THE SAME WINDOW 96.3 55.2 27.5...
  • Page 32 ACK4S INSTALLATION ON BOTTOM HUNG WINDOWS Fig. 25 Fig. 26 Fig. 27 Fig. 28 Fig. 29 INSTALLATION AND USE ISTRUCTIONS...
  • Page 33 ACK4S INSTALLATION ON BOTTOM HUNG WINDOWS Fig. 30 Fig. 31 CAUTION: both must have the SA S2 same stroke in tandem installations Fig. 32 Fig. 31a Fig. 33 Fig. 34 S2 S3 V4 INSTALLATION AND USE ISTRUCTIONS...
  • Page 34 ACK4S DRAWINGS FOR INSTALLATION Wiring diagram INSTALLATION AND USE ISTRUCTIONS...
  • Page 35 ACK4S REMARKS INSTALLATION AND USE ISTRUCTIONS...
  • Page 36 TOPP S.r.l. Società a Socio Unico soggetta a direzione e coordinamento di 2 Plus 3 Holding S.p.a. Via Galvani, 59 - 36066 Sandrigo (VI) - Italia Tel. +39 0444 656700 - Fax +39 0444 656701 Info@topp.it - www.topp.it...

This manual is also suitable for:

Ack4s/230vAck4s/24v
