Base stations
Base stations administration
RPN (Radio Fixed Part Number) Part of the RFPI. Identifies the base station on the air interface.
It also enumerates the base station within a DECT manager. Each DECT manager gets a
group of RPN to assign to its base stations. So it is possible to identify the DECT manager
the base station belongs to.
DECT manager Name of DECT manager the base station belongs to.
Currently always: local
FW Version of the currently installed firmware.
Status Synchronization status of the base station:
0
1
2
3
4
6.1.2 Actions
Edit base station data
 Click on next to the base station you want to edit . . . the data page for the base station is opened (
Delete base station
 Select the check box of one or more base stations
stations are deleted. They are shown in the list of pending base stations again.
6.1.3 Pending base stations
The Pending base stations list shows the automatically recognised DECT base stations in the network that have
not yet been registered. To integrate them into your DECT multicell system, they need to be confirmed and acti-
vated.
The base stations are identified by their MAC address.
Assigning a base stations to your DECT manager
 Click on in the row of the base station you want to add to your system . . . the data page for the base station
is opened.
The relation to a DECT manager cannot be edited and changed. To assign a base station to another
DECT manager:
 Delete it from the Connected base stations list.
 Open a connection to the intended DECT manager.
 Assign the base station from the base stations pending list to the DECT manager.
28
Offline
Deactivated
No Sync
Sync
Sync Overload
Not available
Available but not activated
Activated but not synchronised
Activated and synchronised, 
Synchronised but DECT overload
Click on Delete Confirm with Yes . . . All selected base
OpenScape Cordless IP V2, Administrator Documentation
P31003C1020M1000276A9, 01/2018
p. 29).
