Installation

Pos : 17 /05 Installati on/01 M ec hanisc her Anbau/Ü_M ec hanisc her Anbau @ 0\mod105_2.doc x @ 7347 @ @ 1
5.1

Mechanical connection

Pos : 18 /05 Installati on/01 M ec hanisc her Anbau/Installation Einhängeös e @ 0 \mod112_2.doc x @ 7305 @ @ 1
5.1.1

Suspension lug

● The device is equipped with a suspension lug and can be mounted on various support frames/lifting
devices.
● Take careful that the suspension lug is safety joined with the crane hook and can not slip down.
● The maximum carrying capacity of the support frame/lifting device is not allowed to cross
over by the dead weight of the device and the maximum load.
Pos : 19 /05 Installati on/01 M ec hanisc her Anbau/Installation Las thaken und Ketten @ 0\mod266_2.doc x @ 7403 @ @ 1
5.1.2

Load hook and chains

● Fit suspension ring in the load hook of the lifting equipment.
● Ensure that the single chains are not twisted and may be easily pulled through the jaws
● Attaching the device to the lifting equipment take care that all local safety regulation is observed.
● It is not allowed to exceed the carrying capacity of the lifting equipment with the device
and the maximum load.
