Controller DT61xx, DT61x0/IP
Controller DT61xx, DT61x0/IP
76 (2.99)
52 (2.05)
Mounting
holes for
M4 screws
83 (3.27)
Dimensional drawing controller DT61xx
Dimensional drawing shows the connector side of the controller DT6120
capaNCDT 6110 / 6112 / 6120
Mounting
holes for
M4 screws
Dimensional drawing controller DT61x0/IP
53 (2.09)
76 (2.99)
52 (2.05)
95.2 (3.75)
Dimensions in mm (inches),
not to scale
Page 9
