Sensor Connection - MICRO-EPSILON capaNCDT 6110 Quick Manual

Commissioning
Power Supply, Display/Output Device DT61x0/IP
PIN Color
SCAC3/6/IP
1 white
2 gray
3 pink RS485_A
4 green
5 brown
6 blue RS485_B
Shield
SCAC3/6 is a 3 m long, pre-assembled power supply and output cable.
1) Digital interface with DT6120/IP/U or DT6120/IP/I only
2) Voltage or current output

Sensor Connection

Connection sensor cable
capaNCDT 6110 / 6112 / 6120
Signal Description
+24 V +24 V power supply
GND Supply ground
RS485 interface
1
Analog ground
AGND
(for siganl output)
Voltage output
U-out
(load, min 10 kOhm)
Current output
I-out
2
(max. 500 Ohm load)
RS485 interface
1
Cable shield, housing
2
6
3
View on solder pin side,
6-pin. female cable
connector
Connection power supply
SCAC3/6/IP power supply
and output cable
Page 12
