SPS
Ground Connection, Earthing
Ensure sufficient grounding of the target, for example, by connecting it to the sensor or the power supply ground.
capaNCDT 6110 / 6112 / 6120
PC
Controller
SCAC3/6
DT6120, DT6120/IP
Ammeter/
Voltmeter
SCAC3/5
DT6110, DT6112
DT6110/IP
CCxxx
Sensor
Page 7
