DEMO MANUAL DC1565A

pArts list

ITEM QTY REFERENCE
Required Circuit Components
1 4 C1, C3, C8, C10
2 2 C2, C9
3 2 C4, C11
4 8 C5, C6, C12, C16, C21, C23,
C34, C35
5 1 C7
6 1 C13
7 2 C14, C19
8 3 C15, C26, C27
9 2 C17, C18
10 5 C20, C24, C28, C29, C36
11 1 C22
12 0 R15, C25
13 4 C30, C31, C32, C33
14 1 D1
15 1 JP1
16 1 J1
17 2 J2, J3
18 1 J4
19 1 L1
20 0 L2
21 3 L3, L4, L5
22 0 L6
23 22 R1, R2, R3, R4, R5, R6, R7, R8, R10,
R16, R20, R21, R23, R24, R25, R27,
R28, R33, R34, R35, R36, R47
24 5 R9, R37, R38, R39, R40
25 2 R11, R18
26 1 R12
27 2 R13, R17
28 2 R14, R19
6
PART DESCRIPTION
Capacitor, X7R, 1µF , 10V, 10%, 0603
Capacitor, X5R, 0.1µF , 10V, 10%, 0603
Capacitor, X7R, 47µF , 10V, 10%, 1210
Capacitor, X5R, 0.1µF , 10V, 10%, 0402
Capacitor, X5R, 4.7µF , 6.3V, 20%, 0603
Capacitor, X5R, 2.2µF , 10V, 20%, 0603
Capacitor, X7R, 0.01µF , 50V, 10%, 0603
Capacitor, C0G, 4.7pF , 50V, 5%, 0402
Capacitor, C0G, 8.2pF , 50V, 5%, 0402
Capacitor, X7R, 0.01µF , 16V, 10%, 0402
Capacitor, X5R, 2.2µF , 10V, 20%, 0603
OPT 0402
Capacitor, C0G, 47pF , 16V, 10%, 0402
Diode Schottky, RF SER, 15V, SOT‑23
Header, 2‑Pin 0.079 Single Row
BGA Connector, 40 × 10
Connector, SMA, 50Ω, Straight Mount
Connector, SMA, 50Ω, EDGE‑LANCH
Inductor, 56nH, 0603
OPT 0603
Ferrite Bead, 1206
Bead, OPT 1206
Resistor, Chip, 100, 1/16W, 5%, 0402
Resistor, Chip, 1k, 1/16W, 5%, 0402
Resistor, Chip, 33.2Ω, 1/16W, 1%, 0402
Resistor, Chip, 86.6Ω, 1/16W, 1%, 0402
Resistor, Chip, 86.6Ω, 1/16W, 1%, 0603
Resistor, Chip, 10Ω, 1/16W, 5%, 0402
MANUFACTURER/PART NUMBER
AVX, 0603ZC105KAT2A
AVX, 0603ZD104KAQ2A
Murata, GRM32ER71A476KE15L
AVX, 0402ZD104KAQ2A
AVX, 06036D475MAT2A
AVX, 0603ZD225MAT2A
AVX, 06035C103KAQ2A
AVX, 04025A4R7JAT2A
AVX, 04025A8R2JAT2A
Murata, GRM155R71C103KA01D
AVX, 0603ZD225MAT2A
AVX, 0402YA470KA
Avago, HSMS‑2822‑TR1G
Samtec, TMM‑102‑02‑L‑S
Samtec, SEAM‑40‑02.0‑S‑10‑2‑A‑K‑TR
Connex., 132134
E. F . Johnson, 142‑0701‑851
Murata, LQP18MN56NG02D
Murata, BLM31PG330SN1L
NIC, NRC04J101TRF
Yageo, RC0402FR‑071KL
NIC, NRC04F33R2TRF
NIC, NRC04F86R6TRF
Vishay, CRCW060386R6FNEA
Vishay, CRCW040210R0JNED
dc1565afa
