Parts List - Linear Technology DC1626A Demo Manual

PARTS LIST

1626A-A (DCR Sense)
ITEM QTY REFERENCE
Hardware/Components (For Demo Board Only)
1 4 STAND-OFF
2 23 E1-E12, E14-E25
3 6 J1-J6
4 2 J7, J8
5 2 JP1, JP4
6 4 JP1-JP4
7 2 JP2, JP3
1626A-B (R )
SENSE
ITEM QTY REFERENCE
Required Circuit Components
1 1 C12
2 2 C3, C16
3 3 C4, C10, C13
4 2 C5, C14
5 2 C6, C11
6 1 C7
7 1 C8
8 2 C9, C18
9 2 CIN1, CIN2
10 3 CIN3, CIN4, CIN5
11 4 COUT1, COUT2, COUT5, COUT6
12 4 COUT3, COUT4, COUT7, COUT8
13 2 D1, D2
14 2 L1, L2
15 2 Q1, Q3
16 2 Q2, Q4
17 2 R12, R38
18 1 R13
19 4 R14, R15, R41, R45
20 4 R17, R23, R40, R46
21 1 R21
22 2 R27, R25
23 1 R28
24 1 R31
25 2 R42, R43
26 9 R8, R11, R16, R35, R39, R48, R55, R24, R29
27 2 RS1, RS2
28 1 U1
DEMO MANUAL DC1626A
PART DESCRIPTION
STAND-OFF , NYLON 0.25"
TESTPOINT, TURRET 0.095"
JACK, BANANA
CONN, BNC 5PINS
2MM SINGLE ROW HEADER, 3-PIN
SHUNT
2MM SINGLE ROW HEADER, 4-PIN
PART DESCRIPTION
CAP , X7R 330pF 50V 0603
CAP , X7R 1000pF 16V 0603
CAP , X5R 0.1μF 50V 0603
CAP , X5R 0.01μF 25V 0603
CAP , NPO 47pF 16V 0603
CAP , NPO 220pF 25V 0603
CAP , X5R 4.7μF 16V 0805
CAP , X5R 1μF 16V 0603
CAP , 100μF 35V SIZE-F
CAP , X5R 10μF 35V 1210
CAP , 330μF 2.5V SIZE 7343
CAP , X5R 100μF 6.3V 1206
DIODE, SCHOTTKY SOD-323
IND, 0.68μH
MOSFET, N-CHANNEL LFPAK
MOSFET, N-CHANNEL LFPAK
RES, 100k 1% 0603
RES, 15k 1% 0603
RES, 10Ω 1% 0603
RES, 10k 1% 0603
RES, 45.3k 1% 0603
RES, 2.2Ω 1% 0603
RES, 137k 1% 0603
RES, 20k 1% 0603
RES, 10Ω 1% 0603
RES, 0Ω 0603
RES, SENSE 0.0025 2512
LTC3838 38-LEAD TSSOP
MANUFACTURER/PART NUMBER
KEYSTONE 8831 (SNAP ON)
MILL-MAX 2501-2-00-80-00-00-07-0
KEYSTONE 575-4
CONNEX 112404
SAMTEC TMM-103-02-L-S
SAMTEC 2SN-BK-G
SAMTEC TMM-104-02-L-S
MANUFACTURER/PART NUMBER
AVX 06035C331KAT2A
AVX 0603YC102KAT2A
AVX 06035D104KAT2A
AAC 0603D103KAT2A
AVX 0603YA470KAT4A
AVX 06033A221KAT2A
AVX 0805YD475KAT2A
AVX 0603YD105KAT2A
SUNCON 35HVH100M
TAIYO YUDEN GMK325BJ106MN-T
SANYO 2R5TPE330M9
MURATA GRM31CR60J107ME39L
CENTRAL SEMI. CMDSH-4ETR
WURTH 7443330068
RENESAS RJK0305DPB-00-J0
RENESAS RJK0330DPB-00-J0
VISHAY CRCW0603100KFKEA
VISHAY CRCW060315K0FKEA
VISHAY CRCW060310R0FKEA
VISHAY CRCW060310K0FKEA
VISHAY CRCW060345K3FKEA
VISHAY CRCW06032R20FKEA
VISHAY CRCW0603137KFKEA
VISHAY CRCW060320K0FKEA
VISHAY CRCW060310R0FKEA
VISHAY CRCW06030000Z0EA
VISHAY WSL25122L500FEA
LINEAR TECH. LTC3838EFE
dc1626afa
7
