Quick Reference Guide
DBALL/DBALL2-FORD5 Range Extender Ready (RXT) Installation
Range Extender Ready (RXT)
Range Extender Ready (RXT) is used to amplify the distance covered
by factory remote starters. The interface connects to the vehicle and
uses the same code as the factory remote to remote start the vehicle.
The runtime and features are identical to the OEM remote starter.
Some of the advantages of RXT are greater remote range and 2-way
compatibility.
RXT Operations
The following table describes the behavior of the vehicle in relation to the RXT
feature. The following commands are performed on the aftermarket remote.
Command Engine
Start NOT running.
Start Running.
Runtime
The runtime is equivalent to the amount set for the OEM remote starter, which can
be modified in some vehicles (refer to your vehicle owner's manual for more
information). A maximum of 2 remote starts can be performed between ignition
cycles.
Runtime Reset
The Runtime Reset feature allows the user to return the runtime to its predefined
value. This can only performed ONCE per remote start.
Result
The engine will be started.
The engine will be stopped.
List of Available Commands
Note that the information below is for Viper, Clifford and Python models. Icons and
commands may differ depending on the remote brand and model purchased. Refer
to your authorized installation center for more information.
Button(s) Actions
Press & hold for 1 second to lock.
Press & hold for 1 second to unlock.
Press & hold for 1 second to remote
start.
Press & hold for 5 seconds to activate
the trunk release (optional).
Press
x1 +
rear hatch/tail glass release (optional).*
Press
x3 +
the panic mode.
Press
x1 +
remote starter runtime.
* This output is configurable. see your authorized installation center for more
information.
once, then to activate the
3 times, then to activate
once, then to reset the
