Platform: DBALL/DBALL2
Firmware: FORD5 Range Extender Ready (RXT) Installation
Update Alert: Firmware updates are posted on the web on a regular basis. We recommend
that you check for firmware and/or install guide updates prior to installing this product.
Installation Guide
This guide supports the installation of a DBALL in Range Extender Ready (RXT) mode. This solution
offers two (2) configuration options to control your system; Optional RF Kits or SmartStart (all sold
separately).
Range Extender Ready (RXT) is used to dramatically increase the factory remote start
activation range compared to the factory transmitter. Refer to the Quick Reference Guide
for more information.
Important!
This product is ONLY compatible with vehicles equipped with a factory-installed remote starter.
Index
Vehicle Application Guide...................................................................................................................................................
Installation
Wiring Diagram...................................................................................................................................................................
Vehicle Wiring Reference Chart.........................................................................................................................................
SmartStart/XL202 Installation Notes..................................................................................................................................
Programming
Module Programming.........................................................................................................................................................
Module Reset.....................................................................................................................................................................
Hard Reset.........................................................................................................................................................................
Feature & Option List..........................................................................................................................................................
Feature Programming.........................................................................................................................................................
LED Diagnostics & Troubleshooting...................................................................................................................................
Limited One-Year Consumer Warranty...............................................................................................................................
Quick Reference Guide......................................................................................................................................................
SmartStart Compatible
SmartStart is equipped with D2D, which means it can be connected to an interface module and used in Range
Extender Ready (RXT) mode without the use of a remote starter. See the Module Programming section for
more information.
® Ford is a registered trademark and property of the Ford Motor Company.
Rev.: 20160317
02
03
04
05
06
07
07
08
08
09
11
12
© 2016 Directed. All rights reserved.
