Platform: DBALL/DBALL2
Firmware: CHRYSLER7 Range Extender Ready (RXT) Installation
Update Alert: Firmware updates are posted on the web on a regular basis. We recommend
that you check for firmware and/or install guide updates prior to installing this product.
Installation Guide
This guide supports the installation of a DBALL in Range Extender Ready (RXT) mode. This solution
supports RF Kit or SmartStart compatibility (both sold separately).
The optional Plug & Play T-Harness THCHD3 (sold separately) provides simpler and faster installation.
Range Extender Ready (RXT) is used to dramatically increase the factory remote start activation range
compared to the factory transmitter. Refer to the Quick Reference Guide for more information.
Important!
This product is ONLY compatible with vehicles equipped with a factory-installed remote starter.
Index
Vehicle Application Guide......................................................................................................................................................................
Installation
Without T-Harness.................................................................................................................................................................................
With T-Harness THCHD3......................................................................................................................................................................
SmartStart/XL202 Installation Notes.....................................................................................................................................................
Programming
Module Programming............................................................................................................................................................................
Module Reset & Hard Reset..................................................................................................................................................................
Feature and Option List.........................................................................................................................................................................
Feature Programming...........................................................................................................................................................................
LED Diagnostics and Troubleshooting..................................................................................................................................................
Parking Light Error Codes.....................................................................................................................................................................
Limited One-Year Consumer Warranty..................................................................................................................................................
Quick Reference Guide.........................................................................................................................................................................
SmartStart Compatible
SmartStart is equipped with D2D, which means it can be connected to an interface module and used in Range
Extender Ready (RXT) mode without the use of a remote starter. See the Module Programming section for
more information.
