In the lower part, it is possible to see the variables which belong to the selected Dataset. The meanings of the fields are:
In the field "bType" the data format of the IEC61850 variable is defined;
In the field "Reference" the path of the IEC61850 variable is defined;
In the field "Position" the starting byte of the internal memory arrays where saving/getting the value is defined;
In the field "Start Bit" the starting bit of the byte of the field "Position" is defined (only for BOOLEAN data);
In the field "Conversion" the type of conversion of the value is defined (only for FLOAT32/FLOAT64 data);
In the field "Molt Fact" the multiplication factor for the conversion is defined (if "Conversion" is defined as "ItoF/FtoI");
In the field "Mnemonic" a description of the variable is defined.
Note:
The variables of a IEC61850 Dataset can only be read.
