By clicking on "ADD IEC Device", it is possible to add a new IEC61850 Server. A SCL file has to be selected (the allowed extensions are
.scd, .ssd, .sed, .icd, .iid or .cid). The functional structure of the Server (Logical Devices, Logical Nodes, Data Objects and Data Attributes)
will be visible (Fig. 5). The last leaves in the branches of the structure are the variables which can be added to the "Variables" section on the
right (Fig. 6).
Figure 5: functional structure
