A set of adhesive labels is provided for custom identification of individual Spa-Side Remote buttons. Use a pair of
fine-tip tweezers to carefully adhere the appropriate label at each button.
2-SPEED FILTER PUMP CONTROL
If the system is equipped with a 2-Speed Filter Pump, a 2-Speed Filter Pump Relay Kit (model RLY-LXD) should be
installed at the Power Center in accordance with instructions provided.
There are three ways to configure the 2-Speed Filter Pump control:
1. Automatic configuration:
The system will run the filter pump in "low speed" during normal operation, but will automatically switch the pump
to "high speed" for 5 minutes whenever the filter pump turns on.
It is additionally possible to activate the pump in "high speed" whenever the spa, heater, solar and/or Aux1 (pool
cleaner) is running. To enable the pump to run in "high speed" during these conditions, it is necessary to adjust the 4-
position HI SPD Program Switch, which is located at top center of Lx3000 circuit board. Use the corner of a small
screwdriver or other blunt instrument to slide the appropriate Switch(es) to the ON position:
Switch #1: Enables high speed when spa is running.
Switch #2: Enables high speed when heater is running.
Switch #3: Enables high speed when solar system is running.
Switch #4: Enables high speed when Aux1 (pool cleaner) is running.
Connect RLY-LXD relay control wire into 2SPD Relay Socket.
2. Manual configuration:
The system will run the filter pump in "low speed" during normal operation, but will switch the pump to "high speed"
when an Auxiliary Circuit is activated.
Select an Auxiliary Circuit (Aux1 - Aux6), and connect RLY-LXD control wire into the appropriate Relay Socket.
3. Combined configuration:
The "high speed" is controlled by an Auxiliary Circuit and the HI-SPD Program Switch. Use Dual Circuit Relay
Adapter (model CRA-LX) to connect RLY-LXD relay control wire into an Auxiliary Relay Socket and into 2SPD
Relay Socket.
AUXILIARY VALVE ACTUATORS
It is possible to add Valve Actuators (model CVA-24) to the system to motorize two-port or three-port valves for
custom hydraulic features (such as a pool cleaner, fountain, waterfall, etc.). A total of three Valve Actuators may be
added. Valve Actuators can be activated from any Circuit.
1. Install Auxiliary Valve Module (model MOD-VLV3) at the Lx3000 low voltage compartment in accordance with
instructions provided.
VLV1 VLV2
1 2
WITH WITH
O
N
VLV2 VLV3
VLV1
VLV2
VLV3
COMPOOL 11040A
MOD-VLV3
MOD-VLV3
15
