MadStad Speedmaster Installation
Fork-Mount Brackets:
Attaching the Windshield or Fly Screen:
Rotate locking tabs against
brackets as shown below.
Pull up on the locking tab
and rotate onto the spools.
Remove the factory top bolt on
the bottom fork tree. Install
bracket as shown below but do
not fully tighten.
Set brackets onto aluminum
mounting spools.
Make sure the locking tab is fully
pushed down over the two spools.
Remove the factory bolt on the
top fork tree. Install bracket as
shown then fully tighten both
top and bottom.
Fully seat brackets into the
slots on the spools.
