SNMP COMMUNICATION (Dynamic Map)
In order to read/write the data from/to BACnet side, it is necessary to use specific SNMP commands in order to see the SNMP Input and
write the SNMP Output.
Reading BACnet data from SNMP:
In order to read the data from the HD67726, it is necessary to use the GET command.
Each OID defined in the section "Set SNMP Access -> SNMP Read" will be placed in the MIB tree of the converter.
In addition, it will be possible to read the entire internal map of the converter in memory blocks of 128 bytes: this feature is helpful in phase
of configuration of the converter.
