PIN

The FLX500 uses a PIN (Personal Identification
Number) to access tools that offer fine adjust-
ments, diagnostics, or other special functions.
PIN is used synonymously with password.
When the FLX500 left the factory, the default PIN
was 2468. If you have reset and forgotten your
PIN, contact Data I/O or your local representa-
tive for assistance. For contact information see
Customer Support on page 35.

Electrical Fuse

The FLX500 uses one fuse that is located at the
back of the machine below the power connec-
tion. If you suspect the fuse has failed, replace it
with another 5 Amp, 250 Volt fuse—5 x 20 mm.
To replace the fuse:
Exit the FLX500 Application.
1.
2. Turn off the power by pressing the power
switch once and releasing, and tapping OK
to close the FLX Application if it was open.
3. Unplug the power cord from the FLX.
4. With a small, flat screwdriver, placed at the
small tab, pry the fuse block straight out like
a drawer. See Figure 17.
