zortrax M300 Plus Parts Installation

Glass plate installation
Hide thumbs Also See for M300 Plus:

Advertisement

Quick Links

Download this manual
Glass Plate Installation
SOURCE:
https://support.zortrax.com/glass-plate-installation/

Advertisement

loading
Need help?

Need help?

Do you have a question about the M300 Plus and is the answer not in the manual?

Questions and answers

Related Manuals for zortrax M300 Plus

Summary of Contents for zortrax M300 Plus

  • Page 1 Glass Plate Installation SOURCE: https://support.zortrax.com/glass-plate-installation/...

  • Page 2: Table Of Contents

    Table Of Content Unplugging the Power Cable Platform removal Perforated Plate Removal Cleaning the Heatbed Pogo Pin Module Removal* Glass Plate Installation Securing the Glass Plate, part 1 Securing the Glass Plate, part 2 Platform Installation...

  • Page 3: Unplugging The Power Cable

    Unplugging the Power Cable Turn the printer off and unplug the power cable.

  • Page 4: Platform Removal

    Platform removal Unplug the heatbed cable and carefully remove the platform from the printer.

  • Page 5: Perforated Plate Removal

    Perforated Plate Removal Unscrew the twelve screws that secure the perforated plate to the heatbed. Next, separate the plate from the heatbed. For the M300 Plus, unplug the perforated plate cable before separating the plate from heatbed.

  • Page 6: Cleaning The Heatbed

    Cleaning the Heatbed Clean the heatbed from material residues using a piece of cloth.

  • Page 7: Pogo Pin Module Removal

    Pogo Pin Module Removal* Turn the heatbed over and unscrew the two screws that secure the pogo pin module. Next, remove the module. *This step applies only to the M200 Plus.

  • Page 8: Glass Plate Installation

    Glass Plate Installation Place the glass plate on the heatbed.

  • Page 9: Securing The Glass Plate, Part 1

    Securing the Glass Plate, part 1 Install the four corner clips and secure them with the screws.
  • Page 10 Securing the Glass Plate, part 2 Install the two push-on side clips.

  • Page 11: Platform Installation

    Platform Installation Place the platform in the printer and plug the heatbed cable in. Next, start the platform calibration procedure using the options from the menu*. *For the M200 Plus and M300 Plus, the only available option is manual calibration.

This manual is also suitable for:

M200 plus
