- Page 1 Troubleshooting: Camera Preview Is Blurred SOURCE: https://support.zortrax.com/troubleshooting-camera-preview-blurred/...
-
Page 2: Table Of Contents
Table Of Content Blurry Camera View Unscrewing the Camera Removing the Camera (from the Frame) Unscrewing the Camera's Cover Removing the Camera's Case Recalibrating the Camera's Focus Camera Installation, part 1 Securing the Camera's Cover Camera's Installation, part 2 Securing the Camera Sharp Camera View... -
Page 3: Blurry Camera View
Blurry Camera View To see the preview from the printer’s camera, open Z-SUITE 2 and go to My Devices panel. Select your printer (it should be connected to a local network) and click Camera Preview. If the preview in your printer is out of focus, follow the steps from this manual to adjust focus to the proper point. -
Page 4: Unscrewing The Camera
Unscrewing the Camera Unscrew one screw that secures the camera in the printer’s frame. Use a 2mm Allen key. -
Page 5: Removing The Camera (From The Frame)
Removing the Camera (from the Frame) Remove the camera together with its cable from the printer’s frame. -
Page 6: Unscrewing The Camera's Cover
Unscrewing the Camera's Cover Unscrew the two screws that secure the camera’s back cover. Use a Phillips screwdriver. -
Page 7: Removing The Camera's Case
Removing the Camera's Case Separate the camera from its printed case. -
Page 8: Recalibrating The Camera's Focus
Recalibrating the Camera's Focus Use tweezers and twist the camera’s lens. To control focus in the camera, twist the lens either clockwise (if focus is set too far from the camera) or counterclockwise (if focus is set too close to the camera). -
Page 9: Camera Installation, Part 1
Camera Installation, part 1 Put the camera back in its printed case. -
Page 10: Securing The Camera's Cover
Securing the Camera's Cover Secure the camera’s back cover with the two screws. -
Page 11: Camera's Installation, Part 2
Camera's Installation, part 2 Install the camera with its cable in the printer’s frame. -
Page 12: Securing The Camera
Securing the Camera Secure the camera to the printer’s frame with the screw. -
Page 13: Sharp Camera View
Sharp Camera View Once you complete the following procedure, camera focus should be set properly and the preview should look like, for example, the one in the picture.
