Configure; Power Up - ETC DMX DEBC-1 Installation Manual

ETC Installation Guide
DMX Emergency Bypass Controller

Configure

Set the configuration for the DMX bypass operation at the CONFIG DIP switches, located at S1 on the
control board. By default, all four DIP switches are in the OFF position. See the table below to set the
function of the DMX bypass.
ON
1 2 3 4
OFF
CONFIG
V OUT
INPUT
COM
PANIC IN
OFF Panic look sets all 512 channels to full
ON Panic look is recordable (snapshot)
Switch 3
OFF
OFF
ON
ON

Power Up

1: Verify that incoming power to connected normal/emergency lighting fixtures is wired to an
emergency lighting transfer device, such as the ETC SC1008 Branch Circuit Emergency Lighting
Transfer Switch (BCELTS) or Emergency Lighting Transfer System (ELTS2).
2: Replace the cover on the DMX Emergency Bypass Controller. Be careful not to damage the Test
button and the Normal/Bypass indicator while replacing the cover.
WARNING:
3: Restore power to the main breaker that supplies power to the controller. See
Testing
DMX Emergency Bypass Controller Installation Guide
RECORD
Switch 1: Mode
Switch 4
OFF Deactivates panic look immediately when panic input is released.
ON Deactivates panic look 10 seconds after panic input is released.
OFF Deactivates panic look 30 seconds after panic input is released.
ON Deactivates panic look 10 minutes after panic input is released.
Replace the cover on the DEBC before applying power to avoid electric shock!
for details of how the DMX Emergency Bypass Controller should respond when powered.
Normally Open (NO) maintained panic input
Normally Closed (NC) maintained panic input
Panic Exit Delay
Page 7 of 8
Switch 2: Panic Input
Operational Notes and
